HWIC-4ESW 4pt 10/100 Ethernet switch interface card REMANUFACTURED

The 4-port Cisco® EtherSwitch® 10/100 high-speed WAN interface cards (HWICs) HWIC-4ESW supported on the Cisco 1800 (modular)/1941, Cisco 2800/2900, and Cisco 3800/3900 series integrated services routers offer small-to-large-size businesses and enterprise branch office customers the option to integrate switching and routing in one device. This combination offers ease of configuration, deployment, and management while using the powerful characteristics of Cisco routing and Cisco Catalyst® switching features.

Facebook Twitter Pinterest LinkedIn 分享

HWIC-4ESW Overview


The 4-port Cisco® EtherSwitch® 10/100 high-speed WAN interface cards (HWICs) HWIC-4ESW supported on the Cisco 1800 (modular)/1941, Cisco 2800/2900, and Cisco 3800/3900 series integrated services routers offer small-to-large-size businesses and enterprise branch office customers the option to integrate switching and routing in one device. This combination offers ease of configuration, deployment, and management while using the powerful characteristics of Cisco routing and Cisco Catalyst® switching features.


HWIC-4ESW Specification


Brand Cisco
Part number  HWIC-4ESW-RF
Product Description 4pt 10/100 Ethernet switch interface card REMANUFACTURED
Target Applications Data, voice, and video
Supported Router Platforms Cisco 1800 (modular), Cisco 2800, and Cisco 3800 series integrated services routers:
Cisco 1841 (supports HWIC-4ESW only; no PoE support)
Cisco 2801
● Cisco 2811
● Cisco 2821
● Cisco 2851
● Cisco 3825
● Cisco 3845
• Cisco 1941
• Cisco 2901
• Cisco 2911
• Cisco 2921
• Cisco 2951
• Cisco 3925
• Cisco 3945
Form Factor  Single-wide HWIC form factor
Dimensions (W x D x H)  3.08 x 4.74 x 0.76 in.
Weight 0.17 lb
IEEE Protocols ● Ethernet: IEEE 802.3, 10BASE-T
● Fast Ethernet: IEEE 802.3u, 100BASE-TX
● IEEE 802.1d Spanning Tree Protocol
● IEEE 802.1p CoS for Traffic Prioritization
● IEEE 802.1q VLAN
● IEEE 802.1x Security
● IEEE 802.3x Full Duplex
● IEEE 802.3af Power over Ethernet Standard
RFC RFC 2284, PPP Extensible Authentication Protocol (EAP)
Warranty One year
Lead time 2-3 business days
Shipment DHL, Fedex, Aramex, EMS or per request
