Hydraulic Crimping Machine for Cylindrical Cases
TMAX-CF650 it is a compact cylinder driven crimper for sealing all types of cylinder cases in battery R&D labs ,Standard configuration mold can be used for 18650 cylindrical battery sealing.
Customized die for other cylindrical cell types is available upon request(21700 26650 32650 etc).
Cylinder drive mold for cylindrical battery seal, sealing pressure controlled by manual valve .
|
Sealing pressure
|
10~150kg/cm2
|
|
Air supply
|
compressed air 0.6~1.0MPa
|
|
Power supply
|
220V / 50Hz or 110V
|
|
Power
|
120W
|
|
Outer size
|
385mm X 160mm X 325mm
|
|
Net Weight
|
35kg
|
