Bearing
No.
|
Dimensions(mm)
|
a°
mis.
angle
|
Load
ratings
(KN)
|
Screw
|
Weight
≈ kg
|
|
d
|
B
|
dk
|
C1
|
d2
|
G-6H
|
h1
|
13
|
14
|
17
|
d4
|
de
|
b
|
Dynamic
|
Static
|
|
SIQ12ES1)
|
12
|
10
|
18
|
8
|
35
|
M10X1.25
|
42
|
15
|
59.5
|
16
|
17
|
35
|
13
|
10
|
10
|
17
|
M6x12
|
0.12
|
|
SIQ16ES2)
|
16
|
14
|
25
|
11
|
45
|
M12x1.25
|
48
|
17
|
70.5
|
20
|
21
|
45
|
13
|
10
|
21
|
28.5
|
M6x12
|
0.22
|
|
SIQ20ES
|
20
|
16
|
29
|
13
|
55
|
M16x1.5
|
58
|
19
|
85.5
|
25
|
25
|
55
|
17
|
9
|
30
|
42.5
|
M8x16
|
0.43
|
|
SIQ25ES
|
25
|
20
|
35.5
|
17
|
65
|
M16X1.5
|
68
|
23
|
100.5
|
31
|
30
|
62
|
17
|
7
|
48
|
67
|
M8x16
|
0.67
|
|
SIQ30ES
|
30
|
22
|
40.7
|
19
|
80
|
M22X1.5
|
85
|
29
|
125
|
35
|
36
|
77
|
19
|
6
|
62
|
108
|
M10x20
|
1.25
|
|
SIQ40ES
|
40
|
28
|
53
|
23
|
100
|
M35x1.5
|
105
|
37
|
165
|
45
|
45
|
90
|
23
|
7
|
99
|
156
|
M10x25
|
2.16
|
|
SIQ50ES
|
50
|
35
|
66
|
30
|
120
|
M45x1.5
|
130
|
46
|
190
|
58
|
55
|
105
|
30
|
6
|
156
|
245
|
M12x30
|
3.90
|
|
SIQ60ES
|
60
|
44
|
80
|
38
|
160
|
M58X1.5
|
150
|
57
|
230
|
68
|
68
|
134
|
38
|
6
|
245
|
380
|
M16x40
|
7.15
|
|
SIQ80ES
|
80
|
55
|
105
|
47
|
205
|
M80x2
|
185
|
64
|
287.5
|
82
|
90
|
156
|
47
|
6
|
400
|
585
|
M20x50
|
15
|
|
SIQ100ES
|
100
|
70
|
130
|
55
|
240
|
M110x2
|
240
|
86
|
360
|
116
|
110
|
190
|
55
|
7
|
607
|
865
|
M24x60
|
27.3
|
1) Can not be relubricated
2) Can only be relubricated through the rod end housing.
Can supply rod ends with maintenance-free spherical bearings.
For left-hand thread, suffix "L" is added to bearing number and thread sign. E.g.:SILQ40ES M27×2L-6H
