Description:
Enric manufactures various types of compressor models such as fixed, mobile, low pressure, medium pressure, water cooling, air cooling, etc. are available. It can provide exhaust volume from 0.2-100m3/min, exhaust pressure at 0.2-45Mpa, and can compress air, nitrogen, liquefied petroleum gas, coal gas, natural gas, hydrogen, hydrogen chloride, carbon dioxide, propane, ethylene, ammonia, coke oven Compressors of different specifications for various media such as coal gas and difluoroethane
Features:
(1) The working pressure range is large. Different types of pumps can be selected to obtain different pressure areas, and the input air pressure and output air pressure can be adjusted accordingly. Can reach extremely high pressure, liquid 300Mpa, gas 90Mpa
(2) The flow range is wide. For all types of pumps, only 1Kg air pressure can work smoothly. At this time, the minimum flow can be obtained, and different flow can be obtained after adjusting the air intake.
(3) Easy to control, from simple manual control to complete automatic control can meet the requirements.
(4) Automatic restart, no matter what causes the pressure of the pressure holding circuit to drop, it will restart automatically to supplement the leakage pressure and keep the circuit pressure constant.
(5) The operation is safe, using gas drive, no arc and spark, and can be used in dangerous situations.
(6) The maximum energy saving can reach 70%, because maintaining pressure does not consume any energy.
Technical Parameters
|
No.
|
Type
|
Specifications
|
Equipped power
|
Compression medium
|
Size
|
|
1
|
Z
|
Single row, Z type, direct coupling, reciprocating piston type
|
≤37kW
|
Natural gas、Hydrogen、CO2
|
~2000×2200×2200
|
|
2
|
2V2.5
|
Double row, V type, direct coupling, reciprocating piston type
|
≤55kW
|
Natural gas、Hydrogen、CO2
|
~2500×2200×2200
|
|
3
|
2V4.5
|
Double row, V type, direct coupling, reciprocating piston type
|
≤132kW
|
Natural gas、Hydrogen、CO2
|
~3000×2300×2200
|
|
4
|
2D2.5
|
Double row, D type, direct connection, symmetrical balance type, reciprocating piston type
|
≤55kW
|
Natural gas、Hydrogen、CO2
|
~3500×2200×2200
|
|
5
|
2D4.5
|
Double row, D type, direct connection, symmetrical balance type, reciprocating piston type
|
≤132kW
|
Natural gas、Hydrogen、CO2
|
~4000×2500×2200
|
|
6
|
2D6.5
|
Double row, D type, direct connection, symmetrical balance type, reciprocating piston type
|
≤280kW
|
Natural gas、Hydrogen、CO2
|
~4500×3000×2200
|
|
7
|
2D10
|
Double row, D type, direct connection, symmetrical balance type, reciprocating piston type
|
≤560kW
|
Natural gas、Hydrogen、CO2
|
~7200×5500×3500
|
|
8
|
2D12
|
Double row, D type, direct connection, symmetrical balance type, reciprocating piston type
|
≤600kW
|
Natural gas、Hydrogen、CO2
|
~10000×5500×3500
|
|
11
|
4M4.5
|
Double row, D type, direct connection, symmetrical balance type, reciprocating piston type
|
≤250kW
|
Natural gas、Hydrogen、CO2
|
~6500×3500×2800
|
|
12
|
4M6.5
|
Double row, M type, direct connection, symmetrical balance type, reciprocating piston type
|
≤500kW
|
Natural gas、Hydrogen、CO2
|
~6500×3500×2800
|
|
13
|
4M16
|
Double row, M type, direct connection, symmetrical balance type, reciprocating piston type
|
≤1600kW
|
Natural gas、Hydrogen、CO2
|
~12500×3500×3000
|
Applications:
Compressor equipment is widely used in oil field industry, chemical industry, scientific research, national defense, steel enterprises and other fields.
