Parameter
|
|
Processor
|
ARM M332 bit 108MHz processor
|
|
System Internal Memory
|
RAM 128kbs
|
|
Flash
|
ROM 4Mb
|
|
Button
|
1 button for power and scan
|
|
Prompt
|
LED light/Buzzer/Vibration
|
|
Battery
|
Internal 300mAh rechargeable battery
|
|
LED Status
|
Power/Battery/Bluetooth/Scan Status
|
|
Charging
|
USB 5V
|
|
Dimension
|
45*28*38mm
|
|
Weight
|
40g
|
|
Communication
|
Bluetooth 3.0
|
|
Protocol
|
SPP/HID
|
|
development tools
|
Provides SDK for SPP mode
|
|
Language
|
Java
|
|
Support O.S
|
Android/IOS/Windows
|
|
Scan mode
|
Standard mode/ inventory mode
|
|
Settings
|
Sleep,Buzzer,Vibration,Keyboard etc
|
|
Operating temperature
|
-10° ~ 50°C
|
|
Storage temperature
|
-20°~ 70°C
|
|
Humidity
|
0 ~ 95% (without condensation)
|
|
Protection level
|
IP65
|
|
Collection method
|
CMOS video
|
|
Scan speed
|
1/60 s
|
|
Scan angle
|
Angle 360°, Angle of elevation ± 55°, Angle of deviation ± 55°
|
|
Resolution
|
≥7.5mil
|
|
Code Type
|
QR Code, Data
Matrix,PDF417,UPC-A,UPC-E,EAN-8,EAN-13,ISBN,Code 128, GS1
128,ISBT 128,Code 39,Code 11,Interleaved 2 of 5,Industrial 2 of 5,
Matrix 25, Standard 25,Coba bar,MSI/MSI PLESSEY,GS1 Data Bar
|
