IC660CBB902 | GENERAL ELECTRIC | BUS Control Module

IC660CBB902 This module is missing the faceplate; however, this will not prevent it from functioning properly.



GE    IC660CBB902  !!!  --- sales3@amikon.cn



   Contact:  Jessica

                                Email:     sales3@amikon.cn

                                Skype:     jessica01235483

                                Wechat:   hu18030235311

                                Mobile:   86-18030235311(WhatsApp)









The GE Fanuc IC660CBB90xx Series BUS Control Modules are a required interface between a Series Six Plus PLC and the Genius I/O blocks when they are included in the PLCs I/O system. The Bus Controller module can be placed in any I/O slot in the CPU or in a high-capacity I/O rack located in a CPU station or Local I/O station up to 2000 feet (600 meters) from the CPU. Multiple Bus Controllers can be placed in one rack. Since each Bus Controller consumes 20 units of load, up to 5 modules can be placed in a CPU rack, or 10 modules in a high capacity I/O rack.



A Bus Controller can be placed in an I/O rack in a Remote I/O station if the CPU scan time is greater than 10 ms. However, because of the reduced capacity of the serial I/O communications link, window commands would not be supported. Each Bus Controller can interface up to 30 Genius I/O blocks to the Series Six Plus CPU by twisted pair communications up to 2000 feet (600 meters). The only limit to the number of Bus Controllers in any one PLC system is the l/O capacity of the Series Six Plus CPU. Each Bus Controller, similar to any I/O module, has access to all l/O references on its I/O chain.






General Electrica  IC660CBB902

IC660CBB902 | GENERAL ELECTRIC | BUS Control Module





      sales3@amikon.cn





A 4-segment DIP switch located on the module is used to enable channel selection for Expanded I/O addressing. If Normal (non-expanded) addressing is used or if channel selection is made through I/O Transmitter Modules, no switch setting is necessary.
