Specification
|
Details
|
|
Ordering Information
|
IC693CMM301M
|
|
Module Type
|
Series 90-30 PLC module, providing Global Data communications with up to 7 other PLCs.
|
|
LEDs
|
OK, COM
|
|
Global Data Length
|
Per Communications Module: Up to 256 bits, configurable in 32–bit increments.
|
|
|
Per Series 90–30 PLC: Up to maximum available %G memory.
|
|
Environmental
|
|
|
Operating Temperature
|
0°C to +60°C (+32°F to +140°F)
|
|
Storage Temperature
|
–25°C to +70°C (–13°F to +158°F)
|
|
Humidity
|
5% to 95% (non-condensing)
|
|
Vibration and Shock
|
0.2 inch displacement 5Hz to 10Hz, 1 G 10Hz to 200Hz, 5 G 10ms duration
|
IC693CMM301M is a Genius Communications Module (GCM) which is an intelligent module for the Series 90-30 PLC which offers worldwide connections on a genius communications bus between series 90-30 PLCs and other GE Fanuc PLCs. With the use of genius bus controllers, Series 90-70, Series Six, and Series Five PLCs can easily communicate. 0-32 devices can be linked on a Genius Bus. The Genius bus links to the terminal board on the front of GCM module. The Genius communication module can be put on a Series 90-30 CPU baseplate, an expansion baseplate, or a remote baseplate. In order to ensure high performance of the IC693CMM301, the module should be set up on the CPU baseplate. The genius communication module can be utilized for many applications which may include; monitoring of data by an industrial computer and group to group communications among devices on the bus.
