Rated Voltage 24 volts AC or 24 volts DC
Input Voltage Range 0 to +30 volts DC or 0 to +30 volts AC, 50/60 Hz
Inputs per Module 16 (one group with a single common)
Isolation 1500 volts between field side and logic side
Input Current 7 mA (typical) at rated voltage
Input Characteristics
On-state Voltage 11.5 to 30 volts AC or DC
Off-state Voltage 0 to +4 volts AC or DC
On-state Current 3.2 mA minimum
Off-state Current 1 mA maximum
On response Time 12 ms typical
Off response Time 28 ms typical
Power Consumption: 5V 80 mA (all inputs on) from 5 volt bus on backplane
Power Consumption: 24V 125 mA from the Isolated 24 Volt backplane bus or from user supplied power
All items are Distributor Ready-stock Genuine Brand-new Supplying, please inform us if the other conditions are needed, Used, Open-box, Refurbished, etc.
Allen Bradley - CompactLogix; ControlLogix, Flex I/O, MicroLogix, etc.
Siemens - Simatic S7-300; S7-400; S7-1200; S7-1500; HMI 6AV etc.
ABB - Advant 800xA S800; S200; S400; S500; S600; S700; S900 etc.
GE Fanuc - 90-30; 90-70; PACSystems RX3i, etc.
Honeywell - Experion® PKS; ControlEdge™ HC900; etc.
Many Available just wait for you, feel free to ask to get better deal!!!
