Rated Voltage: 120/240 volts AC
Output Voltage Range: 85 to 264 volts AC, 50/60 Hz
Outputs per Module: 8 (two groups of four outputs each)
Isolation
1500 volts between field side and logic side
500 volts between each group
Output Current:
2 amp maximum per point
4 amps maximum per group at 40 ° C (104°F)
Inrush Current: 20 amps maximum for one cycle
Minimum Load Current: 100 mA
Output Voltage Drop: 1.5 volts maximum
Output Leakage Current:
3 mA maximum at 120 volts AC
6 mA maximum at 240 volts AC
On Response Time: 1 ms maximum
Off Response Time: 1/2 cycle maximum
Power Consumption: 160 mA (all outputs on) from 5 volt bus on backplane
All items are Distributor Ready-stock Genuine Brand-new Supplying, please inform us if the other conditions are needed, Used, Open-box, Refurbished, etc.
Allen Bradley - CompactLogix; ControlLogix, Flex I/O, MicroLogix, etc.
Siemens - Simatic S7-300; S7-400; S7-1200; S7-1500; HMI 6AV etc.
ABB - Advant 800xA S800; S200; S400; S500; S600; S700; S900 etc.
GE Fanuc - 90-30; 90-70; PACSystems RX3i, etc.
Honeywell - Experion® PKS; ControlEdge™ HC900; etc.
Many Available just wait for you, feel free to ask to get better deal!!!
