Rated Voltage: 24 volts DC, 120/240 VAC, 50/60 Hz (nominal - see the following table for exceptions)
Output Voltage Range:
5 to 30 volts DC
5 to 250 VAC, 50/60 Hz
Outputs per Module: Eight isolated outputs
Isolation:Field to Backplane and to Frame Ground
250 VAC continuous; 1500 VAC for 1 minute
Point to Point: 250 VAC continuous; 1500 VAC for 1 minute
Maximum Load
8 Amps resistive maximum per output
20 Amps maximum per module for UL installations Maximum load depends on ambient temperature as shown.
Minimum Load: 10mA
Inrush Current: 8 Amps maximum for one cycle
On Response Time: 15ms maximum1
Off Response Time: 15ms maximum1
Output Leakage Current: 1mA maximum at 250 VAC, (25°C (77°F))
Power Consumption: 6mA (all outputs on) from 5 volt bus on backplane 110mA (all outputs on) from relay 24V bus on backplane
