IC693MDR390 GE Combination Discrete input / output module

The IC693MDR390 is a Series 90-30 Programmable Logic Controller (PLC) platform component module that functions as a combination of discrete input and output modules. This module features Eight (8) discrete input channels that are designed to accept input signal voltage ranges of -30 to +30 VDC with rated or nominal voltage of 24 VDC while the typical input current is 7.5 mA at rated voltage. It also has Eight (8) discrete output channels in the form of Normally Open (N.O.) relay contacts designed for voltage ranges of 5 to 30 VDC, 5-250 VAC along with a 50/60 Hz frequency with each output contact capable of 2 Amperes maximum load current and 4 Amperes, maximum current per common. The IC693MDR390 is a single slot module that is installed to any I/O slot of a series 90-30 baseplate. It can be used with any Central Processing Unit (CPU) modules such as embedded and modular CPUs. It may be installed in a local I/O baseplate, where the CPU is installed, or to an expansion or remote I/O baseplate. The IC693MDR390 input channels have an On-state voltage of 15-32 VDC and an On-state current of 4 mA while the Off-state voltage range is 0-5 VDC and an Off-state current of 1.5 mA. The input channels have a typical response time of 7 ms for both On and Off signal transitions. Conversely, the output channels have a typical response time of 15 ms for both signal transitions. This module has a backplane current consumption of 80 mA when all IO is active and 70 mA with all output energized.
