The T8451C is a high-performance, 40-channel digital output module designed for use with ICS Triplex programmable logic controllers (PLCs). This ruggedized module is ideal for demanding industrial applications and offers a range of features to enhance reliability and performance. It supports a 2A per channel drive capability, short-circuit protection, and open-circuit detection. The module also includes programmable output filters and provides isolation between channels and ground.
With its robust design, the T8451C ensures easy installation and configuration. The hardware incorporates fault tolerance and fault detection mechanisms, allowing for rapid identification of faults across system elements. The Expander Processors are naturally redundant, capable of withstanding multiple faults, and support fixed online repair configurations in adjacent slots, requiring minimal additional consideration.
|
Specification
|
Details
|
|
Manufacturer
|
ICS Triplex
|
|
Product No
|
T8451C
|
|
Product Type
|
TrustedTM Module
|
|
System Supply Voltage Range
|
20 to 32Vdc
|
|
Circuit Type
|
Fault tolerant, fully triplicated with optional line monitoring
|
|
Number of Outputs
|
40 Channels
|
|
Independent Power Groups
|
5 each of 8 outputs
|
|
Operational Output/Field Voltage Range
|
18 to 32V dc
|
|
Power Consumption - Field Supply
|
24W
|
|
Power Consumption - System Supply (24V)
|
24W
|
|
Measurement Range
|
0 to 32V dc
|
|
Maximum Withstanding
|
-1 to 40V dc
|
|
Output Current Rating (Continuous)
|
2A per channel, limited to 8A per power group
|
