Brand
|
Cisco
|
|
Part
number
|
IE-2000-8TC-G-E
|
|
Product
Description
|
IE 8 10/100.2 T/SFP. Base with 1588
|
|
Total
Ports
|
10
|
|
RJ45 Ports
|
8 FE
|
|
Combo Ports
|
2 GE
|
|
Manufacturing license
|
LAN Base
|
|
IEEE 1588
|
Yes
|
|
L2NAT
|
Upgradable to L2NAT via Enhanced Lan Base or
IP Lite license
|
|
Power consumption
|
8-port
downlink models: 12.5-20 W
|
|
Hardware
|
● 256
MB DRAM with ECC memory
|
|
● IEEE
1588v2 FPGA
|
|
● 64
MB on-board flash memory
|
|
● 1GB
removable SD flash memory card (optional)
|
|
● Mini-USB
connector
|
|
Alarm
|
● Alarm
I/O: Two alarm inputs to detect dry contact open or close; one alarm output
relay
|
|
Connectors and cabling
|
● 10/100/1000BASE-T
ports: RJ-45 connectors, 4-pair Category 5 UTP cabling
|
|
Layer 2 switching
|
VTPv3,
EtherChannel, Voice VLAN, Flexlink
|
|
Security
|
IPv4
Port-Security, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard,
802.1x, Guest VLAN. MAC Authentication Bypass, 802.1x Multi-Domain
Authentication, Storm Control, Trust Boundary, Access-List (ACL)
|
|
Quality of service
|
IPv4
Ingress Policing, Rate-Limit, Egress Queuing/Shaping, AutoQoS, PROFINET QoS
|
|
Management
|
Port-Based
DHCP, Storm Control - Unicast, Multicast, Broadcast, SPAN Sessions, RSPAN,
DHCP Server, Customized TCAM/SDM Size Configuration, Embedded Event Manager
(EEM)
|
|
Industrial Ethernet
|
IEEE 1588
PTPv2
|
|
IPv4 routing
|
IPv4
static routing
|
|
IPv6 routing
|
IPv6 host
support, HTTP over IPv6, SNMP over IPv6
|
|
Industrial management
|
Layer 2
switching with 1:1 static Network Address Translation (NAT)
|
|
IPv4 routing
|
RIP,
OSPF, EIGRP, VRF Lite, PIM for L3 multicast routing including sparse (SM) and
dense (DM) mode.
|
|
IPv6 Routing
|
IPv6
Static routing, OSPFv3
|
|
Security
|
FIPS
140-2
|
|
Embedded Event Manager
|
EEM
feature enabled with IP Lite license
|
|
DNA Essentials
|
Additional
features
|
|
Cisco DNA Center
|
Discovery,
topology, inventory, software image management
|
|
Visibility
|
DNA
assurance, Device 360
|
|
Day-zero network bring-up automation
|
Cisco
Network Plug-and-Play application
|
