Impulsed bronze multi jet water meter

LXSG-15R~25R model meter for cold drinking water of 15, 20 and 25 mm. (1/2 ", ¾" and 1 ") in diameter, Brand EMI, metrology class B, velocity and multi-jet type, horizontal installation, with transmission

Facebook Twitter Pinterest LinkedIn 分享
Impulsed bronze multi jet water meter
Mult jet meter scalable to remote reading.
This meter greatly exceeds the technical specifications of the Standard.
Solution for the efficient measurement and commercialization of water.


GENERAL DESCRIPTION

LXSG-15R~25R model meter for cold drinking water of 15, 20 and 25 mm. (1/2 ", ¾" and 1 ") in diameter, Brand EMI, metrology class B, velocity and multi-jet type, horizontal installation, with transmission
magnetic, working pressure of 10 kg / cm2
and maximum test pressure of 16 kg / cm2
, temperature of maximum operation of 30 celsius. With sealed encapsulated seal and adjustable 360° with turn stop, dry dial and direct reading with central indicator for low flows, cover with anti-fog device and antifraud insurance, maximum indication of 99999 m³
These meters are "pre-equipped" for pulse technology with 10pulse or 100 pulse / liter resolution and be scalable without change of record higher than electronic distance reading by radiofrequency, induction electromagnetic (touch) and telephone or instrumentation, the body of the meter is made of bronze and is supplied with two nuts, two NPT threaded connection tubes and two gaskets. The meter's serial number is stored in the body The LXSG-15R~25R water meter is designed according to the specifications of Standard ISO-4064-1995.

BASIC METER COMPONENTS:
  • A body cast in bronze alloy with a copper content of al at least 75%.
  • A total volume record with a maximum indication of 99999 m3 ,sealed and pre-fitted to fit the different remote reading and data storage equipment as required.
  • An anti-fraud cap which has the function of showing any inside the meter, it is necessary to destroy it to gain access to the to the inside of the meter.
  • A lid that provides protection to the totalizer record.

PRINCIPLE OF OPERATION.
The water meter LXSG-15R~25R, belongs to the type of velocity water meters . It is equipped with ainjection, with windows dividing the incoming water jet for distributing it evenly into the chamber, thus generating stability in the rotation of the turbinepulse water meter
