Standards
ASTM D1922,ASTM D1424, ISO 6383, ISO 1974, TAPPI T414, GB/T 16578.2, GB/T 455
Features
u LCD display test data.
u Can test independently without computer; auto process data.
u Built-in printer can print out report.
u Pneumatic hold and release device.
u Software: simple interface, easy to use; real time display test data and curve; can export professional test report.
Specifications
|
Test range
|
0-6400gf 0-18000mN
|
|
Tearing arm
|
104±1mm
|
|
Initial tearing angle
|
27.5°±0.5°
|
|
Gas supply pressure
|
0.6Mpa
|
|
Gas supply port
|
Φ6mm polyurethane pipe
|
|
Indication error
|
within ±0.5% in 20%-90% of max range
|
|
Relative fluctuation
|
within 1%
|
|
Instrument size
|
430mmx370mmx 720mm
|
|
Power supply
|
AC220V 50Hz
|
Configuration
Main machine body, software, communication cable, power cable, 1800gf pendulum, weights (400gf, 800gf, 1400gf, 2800gf, 6400gf, 250gf)
User provide: computer, gas source 0.2~0.4Mpa
