PERFORMANCE PARAMETERS |
|
|
Light Source |
Visible Laser Diode 650nm |
|
Scan Pattern |
20 lines Omnidirectional: 5 flelds of 4 parallel lines |
|
Scan Speed |
1500 scans/s & 75 scans/s |
|
Print Contrast |
30% @ UPC/EAN 100% |
|
Minimum Resolution |
5mil@PCS90% |
|
Depth of Field |
0-216mm for 0.33mm UPC/EAN 100% |
|
ELECTRICAL PARAMETERSMECHANICAL PARAMETER |
|
|
Voltage |
5 Volts |
|
Power |
1.0 watt |
|
Static Current |
270mA |
|
Laser Class |
Meet the Grade I National Criteria for Laser Safety |
|
EMC |
CE & FCC DOC compliance |
|
ENVIRONMENTAL PATAMETER |
|
|
Operating Temperature |
0°C to 45°C |
|
Storage Temperature |
-20°C to 60°C |
|
Humidity |
5% to 85% relative humidity, non-condensing |
|
Light Levels |
Daylight, 5000Lux |
|
Shock |
Designed to withstand 1.5M drops |
