Model IOBC038
PERFORMANCE PARAMETERS
Light  Source Visible Laser Diode 650nm
Line 20Lines
Scan Rate 1380±5% Lines / Second
Scan  Pattern Omnidirectional:5Fileds of 4 parallel lines
Print Contrast 30% minimum reflectance difference
Decode Capability EAN-8, EAN-13, UPC-A, UPC-E, Code 39, Code 93, Code 128, EAN 128, ISBN,ISSN, Codabar, Code 25 non-interleaved, Code 25 interleaved , Matrix 2 of 5, MSI, PostBarcode, etc
ELECTRICAL PARAMETERS
Support Interface PS/2, USB,RS232
Voltage .Power 5VCD±12%  1.6W
Laser-level Class1:IEC60825-1
EMC FCC part 15class B,CE En55022B,VCCI,BSMI
LED Indicator Red and Blue
PHYSICAL PARAMETERS
Weight (pcs) N.W: 474g/pcs  G.W: 768g/pcs
Size (pcs) Host: 115mm*110mm*152mm  Package: 245mm x165mmx132mm
Weight (Carton) 9.6 kg/10pcs
Package
Size (Carton) 680mm*350mm*280mm
ENVIRONMENTAL PATAMETER
Crash resistant Can withstand 1.5M free fall
Operating  0Degrees to 40 Degrees (32Fahrenheit to 104 Fahrenheit)
Storage Temperature -20 Degrees to 40 Degrees (-4 Fahrenheit to 104 Fahrenheit)
Humidity 5% to 95% Relative humidity, Non-condensing
Environmental Sealed to resist airborne particulate contaminants

The third generation, Barcode Scanner with perfect scanning process.

Barcode scanner with the fastest speed ( Explosive ) and top-level, performance. Different bar codes ( colorful / vacuum packing / blur / crumpled / reflective ) can be read easily.



Invention highlight I : Barcode Suture Technique,  (Damged Code ) Signal recognition Restructuring .

Deformation, crumpled code can be read easily.

Invention highlight II : Dual signal automatic error correction techniques. colorful ,

blur, vacuous, reflective barcode swept away

Invention highlight III : Intelligent Identification memory.

Recognize and remember barcode type and quality automatically  while scanning.

Decoding speed can improve 30% while read again.
