Ip65 Round Parking Lot LED Street Light

Round Parking Lot Street Light 30w-120w, 5years warranty >120lm/w

Facebook Twitter Pinterest LinkedIn 分享

IIp65 Round Parking Lot LED Street Light


Features:

  • Spining to all –in-one shaped dissipation,the structure of dissipation adopted hollow cooling structure with good heat sink .
  • Beautiful patten, adopted Philips SMD3030 with 140lm/W. The efficiency of whole lamp up to 100lm/W.
  • Available Optic ：TYPE IV
  • High performance Meanwell driver，5 year warranty .
  •  IP65。



Application:

Mainly applied to outdoor light,factory buildings,ganium,industrial lights,architecture light etc .



Datasheet:

Model  CCT CRI Lumen Watt Size/MM Beam angle  N.W
GD-PL390-W30-NP-XXXXK-A 2700-7000K ≥70 3450LM 30W 481.1*390*201 10,30,60,85*135,100*140，120 4.1KG
GD-PL390-W60-NP-XXXXK-A 2700-7000K ≥70 6900 LM 60 W 481.1*390*201 10,30,60,85*135,100*140，120 4.1KG
GD-PL390-W120-NP-XXXXK-A 2700-7000K ≥70 13800 LM 120 W 481.1*390*201 10,30,60,85*135,100*140，120 4.1KG
GD-PL390-W30-NP-XXXXK-B2 2700-7000K ≥70 3450LM 30W 580.5*390*120 10,30,60,85*135,100*140，120 4.1KG
GD-PL390-W60-NP-XXXXK-B2 2700-7000K ≥70 6900 LM 60 W 580.5*390*120 10,30,60,85*135,100*140，120 4.1KG
GD-PL390-W120-NP-XXXXK-B2 2700-7000K ≥70 13800 LM 120 W 580.5*390*120 10,30,60,85*135,100*140，120 4.1KG
GD-PL390-W30-NP-XXXXK-C2 2700-7000K ≥70 3450LM 30W 601.9*390*120 10,30,60,85*135,100*140，120 4.1KG
GD-PL390-W60-NP-XXXXK-C2 2700-7000K ≥70 6900 LM 60 W 601.9*390*120 10,30,60,85*135,100*140，120 4.1KG
GD-PL390-W120-NP-XXXXK-C2 2700-7000K ≥70 13800 LM 120 W 601.9*390*120 10,30,60,85*135,100*140，120 4.1KG
GD-PL390-W30-NP-XXXXK-D2 2700-7000K ≥70 3450LM 30W 580.5*390*120 10,30,60,85*135,100*140，120 4.1KG
GD-PL390-W60-NP-XXXXK-D2 2700-7000K ≥70 6900 LM 60 W 580.5*390*120 10,30,60,85*135,100*140，120 4.1KG
GD-PL390-W120-NP-XXXXK-D2 2700-7000K ≥70 13800 LM 120W 580.5*390*120 10,30,60,85*135,100*140，120 4.1KG
GD-PL390-W30-NP-XXXXK-E2 2700-7000K ≥70 3450LM 30W 604.6*390*120 10,30,60,85*135,100*140，120 4.1KG
GD-PL390-W60-NP-XXXXK-E2 2700-7000K ≥70 6900 LM 60 W 604.6*390*120 10,30,60,85*135,100*140，120 4.1KG
GD-PL390-W120-NP-XXXXK-E2 2700-7000K ≥70 13800 LM 120W 604.6*390*120 10,30,60,85*135,100*140，120 4.1KG
GD-PL390-W30-NP-XXXXK-F2 2700-7000K ≥70 3450LM 30W 520.7**390*120 10,30,60,85*135,100*140，120 4.1KG
GD-PL390-W60-NP-XXXXK-F2 2700-7000K ≥70 6900 LM 60W 520.7**390*120 10,30,60,85*135,100*140，120 4.1KG
GD-PL390-W120-NP-XXXXK-F2 2700-7000K ≥70 13800 LM 120W 520.7**390*120 10,30,60,85*135,100*140，120 4.1KG
2700-7000K color temp.optional
Input Voltage: AC 90V~305V
Effiency of Power Supply: >95%
Storage temperature: –40 ~ 85°C
