IPBS046 Industrial Wireless 1D Laser Barcode Scanner Inductive charging

Performance Parameter

Light Source

Visible Laser diode ,650nm

Decode Capability

EAN-8,EAN-13,UPC-A,UPC-E,Code 39,Code 93,Code 128,EAN128,Codaber, Industoal 2 of 5,Interleave 2 of 5,Matrix 2 of 5,MSI,etc.

Scanning Type

Single-line

Scan Rate

150 scans per second

Trigger Mode

Manual /continuous scan

Roll/Pitch/Yaw Angle

30° /65°/55°

Resolution

0.10mm(pcs 0.9)

Depth of scanning field

0-250mm（0.33mm.PCS 90%）

Print Contrast

30%,minimum reflective

Error Rate

1/5million

Indicator

LED,buzzer,loudspeaker

Interface Support

USB-HID,USB-COM,RS232

Frequency

433MHz

Transmission range

300M

Memory capability

≤35000 codes

Physical Parameter

Dimension

L158mm*W68mm*H96mm

Housing Materials

ABS+PC

Weight

450g

Cable Parameter

2M

Electrical Parameter

Voltage

DC 5V±1%

Current

20mA(Operating mode),100mA

Battery Capacity

2200mA

Power Supply

DC 5V±@1A

Charge Mode

Cable connecting to charge

Charge Indicator

Orange LED

Environmental Parameter

Operating Temperature

-20℃~50℃

Storage Temperature

-40℃~70℃

Humility

5%-95%(no condensing )

IP Level

IP54

LUX

3000-12000Lux

Impact Resistance

withstands multiple 3m drops to concrete
