IPBS055 1D Linear Imaging CCD handheld Barcode Scanner Support Scan barcode on mobile screen

Performance Parameter

Model IPBS031

Parameter

Input Voltage

5V DC, ±0.25V

DC Current

25mA(Working); 90mA(Max peak); 250mA (Charging)

Light Source

650nm visible Laser diode (1D)

Laser Safety Level

China GB Class II, EN60825-1

Decoding speed

150 times/second

Anguler Tolerance

Skew ±60°;    Pitch ±65°;    Roll ±42°

Resolution

5mil for TS4500;  /  3mil for TS4500H

Scan Speed

Smart detection,speed up to 500 scans per second

Handset Memory

1M byte (can storage 60 thousands commodity bar codes)

Wireless Contact Radius Limit

500 meters

1D Code types

UPC-A, UPC-E,EAN-8, EAN-13, EAN-ISBN/ISSN, Code 39, Code 39(Full ASCII), Industrial 2 of 5,Interleave 2 of 5, Matrix 2 of 5,Codabar, Code 128,Code 93,Code 11 MSI/Plessey, UK/Plessey, UCC/EAN 128, China Post Code,GS1 Data Bar (formerly RSS) etc.

Alert Mode

Indicator and Buzzer

Interfaces

USB, RS232,PS2

Trigger mode

Manual, Continuous Scanning

Mode setting

Set by scanning functional barcodes or by the cradle keys

Temperature

-18°C ~55°C（working）;-40°C ~60°C（storage）

Humidity

5%~90%（Non-condensing）

Shield Materials

ABS/PC+TPU

Dust & Water proof

IP54

Shock proof

withstand multiple drops from 1.8m to concrete surface

Battery Performance

it can work 45hrs consecutively or can last 1 week at normal working time after a 4hrs power charge (full)
