IPBS058 1D CCD Barcode Scanner 660nm visible Red LED

qr reader
1.Trial order acceptable
2.High quality, reasonable
3.Reasonable Price

Performance Parameters
Light Sources:	660nm visible Red LED
Supported symbologies:	UPC- A, UPC-E, EAN-13, EAN-8, Codabar, Code 39,Code 39 Full ASCII, China Post, Plessey，MSI,Code 93, Code 128, Industrial 2 of 5, Interleave 2 of 5, Code 11, ISBN, ISSN, Code 32 (Italian pharm code), Code 39 extended, NVE - 18, PZN, Ean-14, LOG Mars, GS1-128 and ITF-14, SISAS,GS1Omnidirectional, GS1 Limited, Aviation25, RSS 14. etc 1D barcodes (Include screen bar codes)
Scan Method:	ccd imaging sensor
Scan Speed:	≥200times/s
Scan Mode:	Manually/Continuous/Automatic inductive(Optional)
Scan Angle:	Yaw 65°, Rotation 30°, Pitch 55°
Precision:	4mil(0.1mm)
Depth of scan field:	0-250mm(0.33mm,PCS90%)
Error Rate:	1/5million
Interface:	USB-HID,RS232
Physical Parameters
Dimensions	83mm70mm172mm
Weight	205g
Material:	ABS+PC
Cable length	2M
Color	Grey
Environmental Parameters
Operating Temperature	-20℃ to 50℃
Storage Temperature	-40° to 158°F/-40° to 70℃
Humidity	5% to 95% RH.Non-condensing
Shock Resistance:	withstand 3m drops to concrete
Electrical Parameters
Voltage	Operating DC5V ±1%
Current Standby	3uA
Operating	120mA
