Physical Parameter
|
|
Size
|
166mm(L)×77.5mm(W)×22mm(D)
|
|
Weight
|
<500g
|
|
Display screen
|
4.5 inch IPS 480 * 854 PX with Multi-point touch capactive screen.
|
|
Expand port
|
PSAM x 2(optional), Micro SIM x 1 , POGO Pin x 1, Micro SD(TF) card x1
|
|
Communication interface
|
Type-C, USB x 1
|
|
Battery capacity
|
Rechargeable Li-polymer Battery 3.7V 4200mAh Optional. RTC battery keeps time not lost.
|
|
audio frequency
|
Speaker(mono)x1，Microphonex1，headphonex1
|
|
Flashlight
|
Compatible with flashlight and electric torch.
|
|
Acceleration sensor
|
1, 3-Axis 2, Sampling can be adjusted per second, such as 1~100 times.
|
|
Basic function
|
1, Motor*1 2, color lamp*2 3, Optical sensor support
|
|
4, The flashlight brightness is the same as camera flash
|
|
Key
|
29 Silicon keys,Support touch screen soft keyboard and physical keyboard.
|
|
Performance Parameter
|
|
CPU
|
ARM Cortex-A53 64bit Quad-Core 1.3G
|
|
OS
|
Android7.0
|
|
Ram/flash Rom
|
16G Flash ROM and 2GB RAM(8G Flash ROM and 1GB RAM Optional),
|
|
Micro SD/TF card slot(Max up to 32G).
|
|
Typewriting
|
English, Pinyin, five strokes, handwriting input, support soft keyboard
|
|
Language
|
Chinese, English,Korean,Japanese,Malay, Singaporean etc
|
|
Camera
|
8MP autofocus camera with flash
|
|
GPS
|
Support GPS or AGPS
|
|
NFC
|
Support 13.56MHz, ISO1443A/B, 15693, read distance is 2cm-5cm
|
|
Data Communication
|
|
WI-FI
|
Support IEEE802.11a/b/g/n， it need effective wireless LAN signal cover
|
|
4G
|
FDD-LTE (B1/B2/B3/B5/B7/B8/B20)
|
|
TDD-LTE (B40)
|
|
3G
|
WCDMA (850/900/1900/2100MHz)
|
|
2G
|
GSM(850/900/1800/1900MHz)
|
|
Bluetooth
|
Support 2.0+EDR/3.0+HS/4.0+HS Transmission distance is 5-10m
|
|
Scanner engine(Optional)
|
|
1D Laser scanner (optional)
|
Minde SE966 / Honeywell N4313/ Newland EM1300(CCD)
|
|
|
Support Code128,EAN-13,EAN-8,Code39,UPC-A,UPC-E,Codaber,
|
|
Interleaved 2 of 5,China post 25,ISBN/ISSN,Code93,UCC/EAN-128,
|
|
GS1 Databar,HIBC,etc.
|
|
2DCMOS scanner (optional)
|
Newland EM3090 / Newland EM3096/ Honweyll N6603
|
|
|
Support PDF417,MicroPDF417,GS1 Composite,Aztec
|
|
Code,Data Matrix,QR Code,Micro QR Code,MaxiCode,Hanxin Code,etc.
|
|
Operating System
|
|
Standby current
|
≤10mA，Target ：no more than 8mA。
|
|
Temperature
|
-20℃ to 55℃
|
|
Storage
|
-25℃ to 70℃
|
|
Environment Humidity
|
5%RH--95%RH(no condensation)
|
|
Drop specification
|
6 sides can bear impact from 1.5m drop to cement floor about 30 times in the range of operating temperature
|
|
Product certification
|
|
IP rating
|
IP66
|
|
Safety specification
|
IEC2 /FDA Ⅱgrade,conform IEC60825/EN60825-1 standard
|
|
Working life
|
No less than 5 years
|
