Dimensions
|
164.2 x 80.0 x 24.3mm / 6.46 x 3.15 x 0.96in
|
|
Weight
|
654g / 23.07oz
|
|
Display
|
5.2'' IPS FHD 1920x1080
|
|
Touch Panel
|
Corning Gorilla Glass, multi-touch panel, gloves and wet hands supported
|
|
Power
|
Main battery: Li-ion, rechargeable, 8000mAh
|
|
Standby: over 500 hours
|
|
Continuous use: over 12 hours (depending on user environment)
|
|
Charging time: 3-4 hours (with standard adaptor and USB cable)
|
|
Expansion Slot
|
1 slot for SIM card, 1 slot for SIM or TF card
|
|
Interfaces
|
USB 2.0 Type-C, OTG
|
|
Audio
|
Speaker, 2 microphones
|
|
Keypad
|
4 front keys, 1 power key, 2 scan keys, 1 multifunctional key
|
|
Sensors
|
Gravity sensor, light sensor, proximity sensor
|
|
Performance
|
|
CPU
|
Cortex-A53 Quad-core 1.45GHz/Cortex-A53 Octa-core 2.5GHz
|
|
RAM+ROM
|
2GB+16GB（Quad-core）/ 3GB+32GB（Octa-core）
|
|
Expansion
|
Supports up to 128 GB Micro SD card
|
|
Communication(Quad-core)
|
|
WLAN
|
IEEE802.11 a/b/g/n, 2.4G/5G dual-band, internal antenna
|
|
WWAN (China)
|
2G: 900/1800MHz
|
|
3G: 900/1900/2000/2100MHz
|
|
4G: B1, B3, B5, B38, B39, B40, B41
|
|
WWAN (Europe)
|
2G: 850/900/1800/1900MHz
|
|
3G: 850/900/1900/2100MHZ
|
|
4G: B1, B3, B5, B7, B8, B20, B40
|
|
WWAN (America)
|
2G: 850/900/1800/1900MHz
|
|
3G: 850/900/1700/1900MHZ
|
|
4G: B2, B4, B7, B12, B17
|
|
WWAN (Others)
|
Depending on the country's ISP
|
|
Bluetooth
|
Bluetooth 4.0, BLE
|
|
GNSS
|
GPS/AGPS, GLONASS, BeiDou; internal antenna
|
|
Note
|
C72 models being manufactured for Turkish Market, do not include Voice Call (Phone Call) function. WAN module included on those models only support DATA transfer.
|
|
UHF RFID
|
|
Engine
|
CM2000-1 module based on Impinj Indy R2000
|
|
Frequency
|
865MHz-868MHz / 920-925MHz / 902-928MHz
|
|
Protocol
|
EPC C1 GEN2 / ISO18000-6C
|
|
Antenna
|
Linear polarization(1.8dBi); circular polarization (4dBi)
|
|
Power
|
1W (30dBm, +19dBm to +30dBm adjustable)
|
|
R/W ranges
|
＞7m (linear polarization, outdoors); ＞21m (linear polarization, indoors)
|
|
＞10m (circular polarization, outdoors); ＞25m (circular polarization, indoors)
|
|
Reading rates (circular polarization)
|
＞200 tags/s (circular polarization)
|
|
Note
|
*Ranges and rates depend on tags and environment
|
|
Note2
|
*This function is optional
|
|
Camera
|
|
Camera
|
13MP Autofocus with flash
|
|
Iris Recognition
|
|
Rate
|
<150ms
|
|
Range
|
20-40cm
|
|
FAR
|
1/10000000
|
|
Note
|
Protocol：ISO/IEC 19794-6，GB/T 20979-2007
|
|
|
*This function is optional
|
|
User Environment
|
|
Operating Temp.
|
4°F to 122°F / -20°C to 50°C
|
|
Storage Temp.
|
-40°F to 158°F / -40°C to 70°C
|
|
Humidity
|
5% RH - 95% RH non condensing
|
|
Drop Specification
|
Multiple 1.5m/4.9ft drops (at least 20 times) to the concrete across the operating temperature range
|
|
Tumble Specification
|
1000 x 0.5m/1.64ft falls at room temperature
|
|
Sealing
|
Host IP65 per IEC sealing specifications
|
|
ESD
|
±15KV air discharge, ±6KV conductive discharge
|
|
Developing Environment
|
|
Operating System
|
Android 6.0(Quad-core)/Android 8.1(Octa-core)
|
|
SDK
|
Chainway Software Development Kit
|
|
Language
|
Java
|
|
Tool
|
Eclipse / Android Studio
|
|
Communication(Octa-core)
|
|
WLAN
|
IEEE802.11 a/b/g/n/ac, 2.4G/5G dual-band, internal antenna
|
|
WWAN (China)
|
2G: 900/1800MHz
|
|
3G: WCDMA: B1,B8
|
|
CDMA2000 EVDO: BC0
|
|
TD-SCDMA: B34,B39
|
|
4G: B1,B3,B5,B8,B34,B38,B39,B40,B41
|
|
WWAN(Europe)
|
2G: 850/900/1800/1900MHz
|
|
3G: B1,B2,B4,B5,B8
|
|
4G: B1,B3,B5,B7,B8,B20,B40
|
|
WWAN (America)
|
2G: 850/900/1800/1900MHz
|
|
3G: B1,B2,B4,B5,B8
|
|
4G: B2,B4,B7,B12,B17,B25,B66
|
|
WWAN (Others)
|
Depending on the country's ISP
|
|
Bluetooth
|
Bluetooth v2.1+EDR,3.0+HS,v4.1+HS
|
|
GNSS
|
GPS/AGPS, GLONASS, BeiDou; internal antenna
|
|
Barcode Scanning
|
|
1D Linear Scanner
|
Zebra SE965
|
|
2D Imager Scanner
|
Zebra: SE4710
|
|
1D Symbologies
|
UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc.
|
|
2D Symbologies
|
PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX), etc.
|
