Dimensions (LxWxD)
|
150 mm×73.5 mm×16 mm (head 24mm thickness)
|
|
Weight
|
230g (battery included)
|
|
Communication Transmission
|
Wireless WAN
(Network frequency) Asia & Europe：
|
2G：B2/B3/B5/B8
3G：WCDMA：B1/B2/B5/B8 CDMA&EVDO：BC0 TD-SCDMA：B34/B39
4G：FDD-LTE：B1/B3/B7/B8/B20 TDD-LTE：B38/B39/B40/B41
America：
2G：B2/B3/B5/B8
3G：B2/B5
4G：B2/B4/B5/B17
|
|
Wireless WAN (Data service)
|
GSM/GPRS/EDGE/CDMA/UMTS/HSPA/HSPA+/EVDO/WCDMA/TD-SCDMA/TDD-LTE/FDD-LTE
|
|
Wireless LAN
|
Wi-Fi 802.11a/b/g/n (Dual-band Wi-Fi: 2.4G+5G)
|
|
Bluetooth
|
Bluetooth 4.0
|
|
GPS
|
GPS/AGPS/BEIDOU/GLONASS
|
|
Operating Environment
|
|
Development Tools
|
Android SDK+ JDK + Eclipse
|
|
Programming Language
|
Java
|
|
Programming Language
|
|
|
Operating Temp.
|
-20℃ ~ 60℃ (-4℉ ~ 140℉)
|
|
Storage Temp.
|
-40℃ ~ 60℃（-40℉ ~140℉ ）battery included
-40℃ ~ 70℃（-40℉ ~158℉）battery not included
|
|
Relative Humidity
|
0 ～ 95% (non-condensing)
|
|
Drop Specification
|
1.5-meter drops to concrete ground
|
|
Sealing
|
IP65
|
|
Electrostatic Discharge
|
Conforms to ±15 kV air discharge, ±8 kV direct discharge
|
|
1D Laser Scanner 4313的
|
|
Scan Precision
|
5mil
|
|
Rotate Angle
|
±35°
|
|
Pitch Angle
|
±65°
|
|
Skew Tolerance
|
±45°
|
|
Ambient Light
|
Sunlight: 10,000ft. Candles (107,640Lux)
Artificial Light: 450ft. Candles (4,844Lux)
|
|
Scan Frequency
|
104±12 /sec
|
|
Laser Safety Grade
|
Class II
|
|
Code Support
|
UPC/EAN, POST, Code 128, Code 39, Code 93, Code 11, Codabar, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, MSI, RSSI, etc.
|
|
1D / 2D Area Imager（Honeywell6603)
|
|
Scan Precision
|
3mil c39/128
|
|
Rotate Angle
|
360°
|
|
Pitch Angle
|
±45°
|
|
Skew Tolerance
|
±65°
|
|
Scan Frequency
|
1 scans /50ms
|
|
Laser Safety Grade
|
Class II
|
|
Image Resolution
|
844(H)×640(V)
|
|
Image Frame
|
60fps
|
|
Light Source System
|
White light, laser aiming
|
|
Minimum Printing Contrast
|
20%
|
|
Code Support
|
Aztec Code , Codabar , Codablock F , Code 11 , Code 128 , Code 2 of 5 , Code 39 , Code 93 , Data Matrix , EAN/JAN-13 , EAN/JAN 8 , EAN-UCC Composite Codes , EAN-UCC Emulation , IATA Code 2 of 5 , Interleaved 2 of 5 , Matrix 2 of 5 , MaxiCode , MicroPDF417 , MSI , PDF417 , Postal Codes ( Australian Post , British Post , Canadian Post , China Post , Japanese Post , Korea Post , Netherlands Post , Planet Code , Postnet ) , Plessey Code , PosiCode , QR Code , RSS Expanded , RSS Limited, RSS-14 , TCIF Linked Code 39 , Telepen , Trioptic Code , UPC-A , UPC-E, etc.
|
|
NFC （Optional）
|
|
Frequency
|
13.56 MHz
|
|
Reading Distance
|
Within 30 mm
|
|
Protocol
|
ISO14443A/14443B/15693
|
|
Input/Output Ports
|
|
|
USB Port
|
1 (Micro USB port)
|
|
Charger Port
|
1 (Charging interface at the bottom)
|
|
Headset Port
|
1
|
|
OTG
|
Support
|
|
Accessories
|
|
Standard
|
Battery，Power adapter，Screen protector，Hand strap Camera
|
|
Optional
|
Bottom charging cable, USB cable, Single cradle, Charging cradle, 4-slot device cradle, 4-slot battery cradle, Carry case (with wrist strap), Waist bag, Pistol grip
|
