Product parameters
|
|
Performance
|
|
Quad core
|
|
CPU
|
Cortex-A53 Quad-core 64-bit 2.0GHz high-performance processor
|
|
RAM+ROM
|
2GB+16GB Supports up to 3GB+32GB（Optional）
|
|
Expand memory
|
Micro SD(TF) Supports up to 128GB
|
|
System
|
Android 9.0
|
|
CPU
|
Cortex-A53 Octa-core 64-bit 2.0GHz high-performance processor
|
|
RAM+ROM
|
2GB+16GB Supports up to 3GB+32GB / 4GB+64GB（Optional）
|
|
Expand memory
|
Micro SD(TF) Supports up to 128GB
|
|
System
|
Android 9.0
|
|
Data communication
|
|
WLAN
|
Dual-band 2.4GHz / 5GHz, Supporting IEEE 802 a/b/g/n/ac protocol
|
|
WWAN
|
2G：GSM（850/900/1800/1900MHz）
|
|
3G：WCDMA（850/900/1900/2100MHz）
|
|
4G：FDD:B1/B3/B4/B7/B8/B12/B20
|
|
TDD:B38/B39/B40/B41
|
|
Bluetooth
|
Support Bluetooth 2.1+EDR/3.0+HS/4.1+HS Transmission distance 5-10 meters
|
|
GNSS
|
Support GPS, Galileo, Glonass, Beidou
|
|
Physical parameter
|
|
Dimensions
|
147.3mm×71.1mm×13.5mm
|
|
Weight
|
＜500g (Depends on device function configuration）
|
|
Display
|
5.5 inch IPS color display with resolution 720*1440
|
|
TP
|
Corning Gorilla glass, Supports multi-touch
|
|
Supported gloves and we thands
|
|
Battery capacity
|
Rechargeable polymer battery (3.8V 4200mAh) removable
|
|
Standby time >350 hours
|
|
Working time > 12 hours
|
|
Charging time 3-4H, Using standard power adapter and data cable
|
|
Fast charging:1.5H（Optional）
|
|
Expansion Card slot
|
PSAM x 2, Micro SIM card x 1 , TF card × 1
|
|
Communication interface
|
Type-C USB x 1, OTG
|
|
Audio
|
Speaker (mono), Microphone, Earpiece
|
|
Keypad
|
Silicone button: Power button, Volume +/- button,
|
|
Scan button × 2
|
|
Sensor
|
Gravity sensor, Light sensor, Proximity sensor,Vibration motor
|
|
Data collection
|
|
Barcode scanning (Optional)
|
|
2D Linear scanner
|
Honeywell N3601 Honeywell N6603
|
|
2D Symbologies
|
PDF417,Micro PDF417,GS1 Composite,Aztec Code,Data Matrix,QR Code,Micro QR Code, Maxicode,Hanxin Code,etc.
|
|
Camera
|
|
Rear camera
|
13MP HD camera,Support auto focus,Flash, Anti-shake, Macro shooting
|
|
Front camera
|
2MP color camera
|
|
NFC (Optional)
|
|
Frequency
|
13.56MHz
|
|
Protocol
|
Support ISO14443A/B, 15693 agreement
|
|
Distance
|
2cm-5cm
|
|
Language/input method
|
|
Input
|
English, Pinyin, Five strokes, Handwriting input, Support soft keypad
|
|
Language
|
Language packs in Simplified Chinese,Traditional Chinese, English, Korean, Japanese, Malaysian,etc.
|
|
User environment
|
|
Operating temperature
|
-20℃ - 55℃
|
|
Storage temperature
|
-40℃ - 70℃
|
|
Environment humidity
|
5%RH--95%RH(no condensation)
|
|
Drop specification
|
6 sides Supports 1.5 meters drops and 30 times to the concrete within the operating temperature
|
|
Rolling test
|
500×0.5m rolling for 6 sides
|
|
Protection level
|
IP66
|
|
Accessories
|
|
Standard
|
Adapter, Data cable, Protective film,Instruction manual
|
