ISO19794 Standard FAP30 Android Windows Linux Multiple Fingerprint Reader

ISO19794 Standard FAP30 Android Windows Linux Multiple Fingerprint Reader model SF85 is with big scanning window and could work with different development environment for multiple user case



Product Name: ISO19794 Standard FAP30 Android Windows Linux Multiple Fingerprint Reader model SF85


Technical Specification:


FP type: LES Technology,Optical Fingerprint Sensor

Sensor size: 38mm x 38mm

Effecitve area: Two flat thumbs up to 32.5mm*32.5mm

Image Size: 640*640pixels

Active scanning Windows Rolled finger up  500 dpi

SENSOR Optical Sensor

Dimension: 114 x 64 x37 mm

International Stardard:  ISO19794 FBI CJIS-RS-0010 IAFIS Image Quality Specification Appendix F
Communication USB2.0,Micro-USB
Operating System: Microsoft Windows up to Win10 in 32-bit and 64-bit configuration
Linux Ubuntu and Android 4.0 and Above
SDK: SW  GB_FFD SW Antispoofing detection
working voltage Voltage: 3.3/5V
Current Current: <200ma
Working Environment:Working temperature :0 ℃+ 55 ℃
Working Humidity:17%– 96%


Android FAP30 Multiple Fingerprint Scanner model SF85 Overview



SFT Android FAP30 Fingerprint reader


SF85 Multiple fingerprint Scanner could work with Android, windows as well as Linux System


Windows FAP30 multiple fingerprint Reader



Packing Information:

Acessories:

1pcs*USB fingerprint reader  1pcs* user manual

Dimension: 120*70*45mm

Weight: 156g/pcs



Linux FAP30 Fingerprint reader model SF85 could be used widely for various Government Project like Customs or ID card Registration with cheap cost....
