JJU Metal Rectangle Corrugated Compensator
The rounded rectangle compensator adopts rectangular section and rounded waveform. The single expansion joint in the pipeline bears two-dimensional displacement.The elbow joint pipe composed of two expansion joints can withstand three dimensional displacement.Rectangular round corner metal compensator products are full height, half height, according to the size of the flue, stress and strain requirements of the user can be multi-wave selection.
The product is one of the auxiliary equipment of smoke duct in power station.The CE waveform fillet rectangle compensator adopts rectangular section with fillet waveform. The single expansion joint in the pipeline bears two-dimensional displacement.The elbow joint pipe composed of two expansion joints can withstand three dimensional displacement.Rectangular round corner metal compensator products are full height, half height, according to the size of the flue, stress and strain requirements of the user can be multi-wave selection.
Code:JJU Model Sign:JJU Corrugated pipe type Pressure-Length*Width-Height-Compensator
Lp x Ls (mm)
|
1000x800
|
1500x800
|
2000x800
|
2500x800
|
3000x800
|
n
|
2
|
4
|
2
|
4
|
2
|
4
|
2
|
4
|
2
|
4
|
Compensator Xo(mm)
|
42
|
21
|
42
|
21
|
42
|
21
|
42
|
21
|
42
|
21
|
|
L
(mm)
|
L0
|
310
|
470
|
310
|
470
|
310
|
470
|
310
|
470
|
310
|
470
|
|
L2
|
360
|
520
|
360
|
520
|
360
|
520
|
360
|
520
|
360
|
520
|
|
L3
|
410
|
570
|
410
|
570
|
410
|
570
|
410
|
570
|
410
|
570
|
|
L4
|
460
|
620
|
460
|
620
|
460
|
620
|
460
|
620
|
460
|
620
|
|
KX (Kgf/mm)
|
0.0211
XL'
|
0.0106
XL'
|
0.0211
XL'
|
0.0106
XL'
|
0.0211
XL'
|
0.0106
XL'
|
0.0211
XL'
|
0.0106
XL'
|
0.0211
XL'
|
0.0106
XL'
|
Lp x Ls (mm)
|
3500x800
|
4000x800
|
5000x800
|
4500x1120
|
3171x2716
|
n
|
2
|
4
|
2
|
4
|
2
|
4
|
2
|
4
|
2
|
4
|
Compensator Xo (mm)
|
21
|
38
|
21
|
38
|
21
|
38
|
21
|
38
|
21
|
38
|
|
L
(mm)
|
L0
|
310
|
470
|
310
|
470
|
310
|
470
|
310
|
470
|
310
|
470
|
|
L2
|
360
|
520
|
360
|
520
|
360
|
520
|
360
|
520
|
360
|
520
|
|
L3
|
410
|
570
|
410
|
570
|
410
|
570
|
410
|
570
|
410
|
570
|
|
L4
|
460
|
620
|
460
|
620
|
460
|
620
|
460
|
620
|
460
|
620
|
KX (Kgf/mm)
|
0.0211
XL'
|
0.0357
XL'
|
0.0211
XL'
|
0.0357
XL'
|
0.0211
XL'
|
0.0357
XL'
|
0.0211
XL'
|
0.0357
XL'
|
0.0211
XL'
|
0.0357
XL'
|
Packing & Delivery :
Packing Details : all by seaworthy plywood case and packed strongly by packing belt as below
Delivery Details : Generally it is 5-10 days if the goods are in stock. or 15-30 days if the goods are OEM or not enough
subject to the order quantity. But anyway,normally, we are able to make sure the delivery will not exceed 45 days.
