General application
Pressure and differential pressure transmitters Type 4304 are suitable for measuring overpressure, vacuum and differential pressure of non-corrosive gases.
Preferred areas of application are: HVAC, level measurement (bubbling-through method), flow
measurement and monitoring, and filter technology.
On request, the instrument can be supplied with LC display or with LC display and limit con-tact(s).
● Process connection： Thread; hose connection
● Accuracy (linearity)： 1 %
● Medium temperature： -10 to +50 °C
● Output： 4 to 20 mA, two-wire; 0 to 20 mA, three-wire; DC 0 to 10 V, three-wire
● Input： 0.50 to 1200 mbar DP, relative
● Special features： With switching contacts; very small measuring ranges; adjustable; with LCD display as optional extra
Basic type
| 404304/000 |
Pressure and differential pressure transmitter with inductive measuring system |
| 404304/011 |
Pressure and differential pressure transmitter with one limit contacta |
| 404304/012 |
Pressure and differential pressure transmitter with two limit contactsa |
| 404304/013 |
Pressure and differential pressure transmitter with LCD display 3 1/2-digit |
| 404304/014 |
Pressure and differential pressure transmitter with one limit contact and LCD display 3 1/2-digita |
| 404304/015 |
Pressure and differential pressure transmitter with two limit contacts and LCD display 3 1/2-digita |
Stock versions
| Article |
Part no. |
| 404304/000-408-405-27-298 |
00382800 |
| 404304/000-410-405-27-298 |
00384775 |
