Application
• Food & pharma
• CIP/SIP systems
• Machine and system construction
• Air conditioning and refrigeration system construction
Brief description
The JUMO DELOS SI high-precision, electronic pressure switch with analog output meets technical requirements relevant to hygiene. In a readily cleanable design and with a front-flush, sealfree measuring system, it is specifically geared to hygienic process safety standards. The nominal measuring ranges set at the factory extend from 400 mbar to 60 bar. They can be rescaled
in the ratio 1:4, allowing the user to perform several measurement tasks with just one measuring
instrument.
The following output variants are available, depending on the application: 1× PNP or 2× PNP
switching outputs or 1× PNP switching output and an analog output signal.
The process pressure is visualized by a large, positively lit LC display.
Configuration can simply be performed on the measuring instrument, or by using the more convenient setup program. The enclosure can be rotated ±160° to make it easier to read, and the
display can be rotated 180° for overhead mounting.
A high-temperature variant is available for hot media up to 200 °C (CIP and SIP cleaning systems).
The device is certified according to EHEDG in the versions with process connections (clamp)
DN 25, 32, 40, and 50 as well as JUMO PEKA.
● Measuring range： 0 to 60 bar relative, absolute
● Accuracy (linearity)： 0.1 to 0.15 %
● Output： 1x PNP switching output, 2x PNP switching output, 1x PNP switching output, and 1x analog output) (either: 0(4) to 20 mA, 0 to 10 V)
● Special features： Programmable, switching output, measuring range scaling 1:4, selectable measuring unit, housing and process connection made of stainless steel (316L)
● Process connection： Thread, hygienic connections, diaphragm seals, JUMO PEKA
● Medium temperature： -25 to +200 °C
● Ambient temperature： -25 to +75 °C
Stock versions
| Order code |
Part no. |
| 405052/000-452-475-504-20-36-01/000 |
00528746 |
| 405052/000-454-475-504-20-36-01/000 |
00527029 |
| 405052/000-457-475-504-20-36-01/000 |
00528156 |
| 405052/000-459-475-504-20-36-01/000 |
00520630 |
| 405052/000-461-475-504-20-36-01/000 |
00528994 |
| 405052/000-449-475-504-20-36-01/000 |
00523317 |
Accessories
| Article |
Part no. |
| PC interface cable including USB/TTL converter² |
00456352 |
| Y transmitter cable,5 polea |
00507861 |
| Combination tool |
00526614 |
| Cable connector,straight,4 pole,M12×1,2 m PVC cable |
00404585 |
| Cable connector,angled,4 pole,M12×1,2 m PVC cable |
00409334 |
| Cable socket,5 pole,M12×1,straight,without connecting cable,assembly by customer |
00419130 |
| Measuring device holder for wall and 2"pipe |
00597711 |
| CD-setup programa |
00522384 |
The setup program can only be used for configuration in conjunction with these accessories
Software
| Designation |
Part no. |
| Setup JUMO DELOS 405050² |
00522384 |
The setup program can only be used for configuration in conjunction with these accessories
