Brief description
High application flexibility and the latest connection technology are the essential equipment
features of this new thermostat series.
The thermostat case is suitable for all common installation types such as wall mounting, immer-
sion sleeve, and contact fastening. It can be used universally and reduces the variant range be-
cause different mounting types must no longer be taken into account.
The JUMO heatTHERM-DR (type 7+8) type is a specific variation with a special housing bottom
section for DIN rail or wall mounting. As a result, easy mounting on mounting rails TH35 accord-
ing to DIN EN 60715 (e.g. in control cabinets) is possible. This variant considerably reduces the
mounting time. The flue gas automatic reset temperature limiter JUMO heatTHERM-AT locks
the gas/oil vessel that is connected in parallel with the wood vessel to a chimney.
For these international innovative surface-mounted thermostats with "Push-In®" terminal tech-
nology, the connection wires are only inserted into the terminal point up to the stop - that's it!
No tool is required for connecting the wire or strand with a ferrule and the wiring becomes safer.
In this manner, the costs and time required for connection are considerably reduced compared
to the conventional screw terminal.
The "Push-In®" terminal technology allows direct switching of loads up to 16 A at 230 V AC. The
installation costs can be reduced further because a load contactor is no longer required.
Available are temperature controllers (TR), temperature monitors (TW), safety temperature mon-
itors (STW), safety temperature limiters (STB) as single or double thermostats, and flue gas tem-
perature monitors (ATW).
Approvals according to DIN EN 14597, DGRL, and UL indicate the high quality standards for
this product series.
