JUMO MIDAS S05 401010 OEM pressure transmitter

● Output：4 to 20 mA two-wire; DC 0 to 10 V three-wire

● Process connection：All screw connections that are standard in the industry

● Accuracy (linearity)：0.2 to 0.3 %

● Medium temperature：-40 to +125 °C

● Input：0 to 100 bar relative pressure; 0 to 40 bar absolute pressure

● Measuring system：Silicon sensor with stainless steel separating membrane

JUMO MIDAS S05 OEM Pressure Transmitter – Universal   Applications ● HVAC (heating, ventilating, and air conditioning) ● Refrigeration engineering ● Compressor engineering ● Machinery and plant engineering ● Packaging industry   Brief description The pressure transmitter is available with relative pressure and absolute pressure measuring ranges. The fully welded measuring system (without seals) made of high-grade stainless steel allows this device to be used in almost all media, even in harsh conditions. The structure ensures optimum protection against process medium leakage. The device features a silicon sensor that is extremely resistant to overloading even in the lowest measuring ranges and is capable of handling millions of pressure cycles.

Type 401010 with cable socket                 Type 401010 with M12 × 1 connector

Customer benefits ●   Economic      A high degree of automation (digital compensation and calibration of sensor module) reduc-      es production time and manufacturing costs. ●   Process reliability      The piezoresistive silicon sensor has a high level of overload protection and long-term sta-      bility. The full final inspection in the fully automated measuring and calibration facility en-      sures that each pressure transmitter is of high quality. ●   Time-saving, uncomplicated, and versatile      The installation of the measuring device requires little work and the electrical installation is      simple. The modular structure allows universal use in almost any application.

Special features ●   1 to 100 bar relative pressure,      and also up to 25 bar absolute pressure ●   High degree of process reliability due to a      welded measuring system with no seals ●   Robust and maintenance-free measure-      ment technology thanks to extreme over-       load resistance ●   60 % quicker device installation with the      QUICKON quick-clamp technology ●   Robust construction guarantees a long      operating life ●   Wetted stainless steel parts
