RTD Temperature Probe
for the Food/Pharmaceutical Industry
• For temperatures between -50 and +250 °C
• Protection type up to IP69 according to DIN EN 60529 (IP69K according to DIN 40050)
• Hygienic process connection
• Stainless steel protection tubes
• Available with two-wire transmitter
• CIP-compliant insertion
The RTD temperature probes can be built with terminal heads made of stainless steel or die-cast
aluminum.
Various process connections are available for the different requirements of sub-areas in the food/
pharmaceutical industry. These include screw connections G 3/8, G 1/2 with CIP-compliant conical seal, taper sockets with union nut (dairy pipe fitting), clamping sockets (clamp), movable ball
welding sockets with threaded fitting, welding sockets with CIP-compliant conical seal,
VARIVENT® connections, and ball welding sleeves.
Additionally, basic types 902810/40 and 902810/41, which are designed for use with hygienic
thermowells according to data sheet 902812, are available.
The protection tubes are made of stainless steel.
The RTD temperature probes for the food/pharmaceutical industry are suitable for use in a temperature range from -50 to +250 °C.
High accuracy is ensured by single or double Pt100 temperature sensors according to DIN EN
60751, class A.
Optional analog or programmable two-wire transmitters can be used for longer transmission distances.
● Operating temperature： -50 to +250 °C
● Approvals： SIL and PL compatible
● Protection fitting： Stainless steel 316L
● Measuring circuits： 1/2
● Sensor： Pt100
● Process connection： Thread, hygienic connections, screw connections, JUMO PEKA, CIP-compliant process connections, including electropolished Ra< 0.8 µm, hygienic thermowells
● Terminal head： Form B, BUZ, BUZH, stainless steel terminal head
● Option： Head transmitter
● Declaration of conformity： EC 1935/2004 material confirmation
● Output： Pt100 passive; 1 × analog output 0(4) to 20 mA, 0 to 10 V; 1 × programmable transmitter output 4 to 20 mA
● Protection type： IP67/IP69K
● Accuracy： Tolerance class: class A (class AA as optional extra)
● Areas of application： Food and pharmaceutical applications, CIP and SIP plants, mechanical and plant engineering, refrigeration and air-conditioning engineering
Stock versions
| Order code |
Part no. |
| 902810/20-1001-2-6-25-380-24/452 |
00466457 |
| 902810/20-1001-2-6-100-380-24/452 |
00381830 |
| 902810/20-1001-2-6-25-611-24/452 |
00407336 |
| 902810/20-1001-2-6-25-613-24/452 |
00405849 |
Accessories for transmitter type 707014 (data sheet 707010)
| Description |
Part no |
| Setup program,multilingua |
00605080 |
| PC interface with USB/TTL converter |
00456352 |
Accessories for transmitter type 707050 (data sheet 707050)
Advantage Products
| Description |
Part no. |
| Setup program,multilingua |
00574959 |
| USB cable,A connector to Mini-B connector,length 3 m |
00506252 |
