Technical data
| Areas of application |
Sterilizers, pharmaceutical and food industry, institutes, research facilities |
| Special features |
Cable made of FEP, PTFE, silicone |
| Process connection |
Thread, flange |
| Operating temperature |
-70 to +200 °C |
| Features |
Steam-tight, high protection type |
| Protection fitting |
Stainless steel, steel, ceramic |
|
Push-in resistance thermometers
in steam-tight version
■ for temperatures from -70 to +200°C
■ as single, twin or triple resistance thermometer
■ in 2-wire, 3-wire or 4-wire circuit
■ connecting cable in PTFE, FEP and silicone
Push-in resistance thermometers are preferably used for temperature measurement in
sterilizers. Thanks to their special construction, they are highly suitable for application in
pressurized atmospheres containing steam. Other applications include plant engineering
and laboratories.
The PTFE connecting cable is suitable for use in humid areas within the temperature range
-190 to +260°C, the FEP cable from -70 to +200°C. The cable connection incorporates
strain relief.
The measuring insert is normally fitted with a Pt100 temperature sensor to EN 60 751,
Class A in 2-wire circuit. Versions with 2 or 3 measuring circuits are also available. 3-and
4-wire circuit connections can be provided.
|
 |
| Stock versions |
Sales No. |
| 902830/10-370-1011-2-6-100-11-2500/317 |
90/00306448 |
| 902830/10-370-2001-2-6-100-11-2500/000 |
90/00306449 |
| 902830/30-302-1011-2-4-50-11-2500/000 |
90/00445084 |
| 902830/30-302-2011-2-4.5-50-11-2500/000 |
90/00445085 |
