Model:
GT2-A12K
SPECIFICATIONS
|
Model
|
GT2-A12K
|
|
Detection system
|
Quartz glass scale, CMOS image sensor projection system, Absolute type (without tracking error)
|
|
Measuring range
|
12 mm 0.47"
|
|
Resolution
|
0.1 μm 0.004 Mil
|
|
Indicated accuracy
|
1 µm 0.04 Mil (p-p)*1
|
|
Measuring force
|
Downward mounting
|
1.2 N*2
|
|
Side mounting
|
1.1 N*2
|
|
Upward mounting
|
1.0 N*2
|
|
Sampling cycle
|
1 ms
|
|
Fluid used
|
Dry air
|
|
Operation indicator light
|
2-color LED (red, green)
|
|
Environmental resistance
|
Enclosure rating
|
IP67*3
|
|
Pressure resistance
|
1 MPa
|
|
Applied pressure range
|
0.25 to 0.5 MPa
|
|
Ambient temperature
|
0 to +55 °C 32 to 131 °F (No freezing)
|
|
Relative humidity
|
35 to 85 % RH (No condensation)
|
|
Vibration resistance
|
10 to 55 Hz, Double amplitude 1.5 mm 0.06", 2 hours in each of the X, Y, and Z directions
|
|
Shock resistance
|
1,000 m/s2 (IEC60068-2-27)
|
|
Materials
|
Main body
|
Main body case: Zinc die-casting; Cylinder part: Aluminium alloy;
Air joint resin part: Polyacetal; Air joint metal part: Brass nickel plating; Indicator: Polyarylate
|
|
Dust boot
|
NBR
|
|
Contact
|
TYPE304 Stainless steel, super-tough tungsten alloy*4
|
|
Sensor head cable
|
Optional (connect to the M8 connector)
|
|
Weight
|
Approx. 145 g (excluding cable)
|
