KRC 118 73/2 R1F Ericsson Remote Radio Unit RRUS 01 B3 1800MHz
Product Description
|
DUL21 01
|
KDU 137 834/1
|
KDU 137 834/1 R1C
|
DUL contains the baseband, control and exchange, and for LET RBS S1 and the Mub interface.
|
|
TCU 02 01
|
KDU 137 739/1
|
KDU 137 739/1 R1G
|
|
|
MU
|
SVB 154 600/23
|
SVB 154 600/23 R1C
|
The main control unit, can be placed in the two block of DUG20.
|
|
SUP 6601
|
BFL 901 009/1
|
BFL 901 009/1 R3B
BFL 901 009/1 R3C
|
MU shell power and alarm system, to provide power for the DUG.
|
|
RRUS 01 B0
|
KRC 118 72/1
|
KRC 118 72/1 R1A
KRC 118 72/1 R1F
KRC 118 72/1 R2A
KRC 118 72/1 R2E
KRC 118 72/1 R3A
|
Output power: 4X15W/ 900M 4 carrier / receiving sensitivity: -113dBm
|
|
RRUS 01 B1
|
KRC 118 76/1
|
KRC 118 76/1 R2C
|
4 carriers,Output power of 4X15W or 4X20W (IPM),Input voltage: -48 VDC or AC.
|
|
RRUS 01 B3
|
KRC 118 73/2
|
KRC 118 73/2 R1F
KRC 118 73/2 R2D
KRC 118 73/2 R3A
|
Output power: 4X15W/ 1800M 4 carrier / receiving sensitivity: -113dBm
|
|
RRUS 02 B0
|
KRC 161 264/1
|
KRC 161 264/1 A1G
KRC 161 264/1 R1G
KRC 161 264/1 R1K
|
24 carriers 25MHz(900MHz),MU: -48V RRU: -48V/AC,Only for RBS6000.
|
|
RRUS 12 B3
|
KRC 161 282/2
|
KRC 161 282/2 R1E
KRC 161 282/2 R1F
KRC 161 282/2 R1H
KRC 161 282/2 R1J
|
8 carriers,Output power of 4X15W or 4X20W (IPM),Input voltage: -48 VDC or AC
|
|
ACCU
|
BMG 907 040/1
|
BMG 907 040/1 R1B
|
|
|
PSU AC 02
|
BML 901 250/1
|
BML 901 250/1 R1D
|
RBS6601 RRU outdoor AC power module
|
RBS6601 uses the typical configuration of RRUS 01 B0:
Single band S8/8/8, for example:900MHz or 1800MHz.
Dual band S4/4/4 (900MHz) +S4/4/4 (1800MHz).
Treatment of RRUS01 RF unit responsible for radio frequency signals.
RF performance:
· GSM, WCDMA, LTE
· 4 carriers over 20 MHz IBW
· Output power 4x15W or 4x20W(IPM)
· The receiver sensitivity -113dBm
Size & weight
· Size: 600 x 350 x 112 mm
· weight: 20kg
Power Supply
· The input voltage: -48 VDC or AC
Environmental Science
· Temperature range: -40ºC to +55 ºC
Product Details
Our Advantages
We have Ericsson RRUS 01 B3 for sale, including refurbished and new ones, and the price is usually 90% lower than the original supplier's price. Our super fast turnaround time and high-quality inventory all over the world mean that we can accurately deliver the products replaced on the same day to the place where they are needed, and minimize network downtime.
Ericsson RRUS 01 B3, like all our hardware, takes comprehensive warranty as the standard. Whether you need new products or renovated products, we only purchase green market equipment of the highest quality and environmental protection. All these are provided at the best possible price, and a large amount of cost-effectiveness will be directly passed on to you.
Ericsson RRUS 01 B3 represents only one product in our world-class hardware portfolio. The portfolio includes very well-known industry names, such as Nokia, Huawei, ZTE, Siemens, Nortel, Ericsson, Alcatel, Lucent, etc. We have a lot of inventory, thank you very much for sharing with customers.
