Touch Screen Controlled Viscosity Meter for Lab Battery Slurry Preparing
NDJ Series touch screen viscometer is perfectly integrated with the touch screen technology, and the viscosity can be measured with a fashion, modern and high technology rapidly, accurately and directly. Various parameters and working conditions can be completely and directly displayed on the 5 inch ultra-large colorful touch screen. Various parameters can be measured, displayed and read directly in high accuracy, the instrument can be displayed conveniently, used to replace similar imported products, and it leads the new trend of science and technology of viscometers made in China.
The main features of the instrument
5 inch full colorful touch screen
- Brand new user's interface
- Enhanced control
- Real-time trend display
- CH/EN operating interface
Displayed information
- Viscosity cp
- Temperature °C
- Dynamic viscosity mm/s2
- Density g/cm3
- Torque %
- Shear rate/ shear stress
- Rotating speed/ rotor
Internal options
- Timed measuring
- Programmable QC upper and lower limit warning
- Automatic measuring range displaying
|
Item
|
Performance
|
AOT-NDJ-8S
|
AOT-NDJ-8T
|
|
1
|
Display
|
LCD
|
5 inch color touch screen
|
|
2
|
Operation
|
Touch-button
|
5 inch color touch screen
|
|
3
|
Measuring range (mPa.s)
|
1-2,000,000 (2 Million)mPa.S，Use0-4#Rotor
(Measuring the ultra-low viscosityless than10mPa.S,need to buy 0# rotor)
|
|
4
|
measurement accuracy
(Newton liquid)
|
±1%
|
±1%
|
|
5
|
Repeat accuracy (Newtonian liquid)
|
±0.5%
|
|
6
|
Speed (r/min)
|
0.3, 0.6，1.5，3，6, 12, 30, 60
|
|
7
|
Rotor
|
1#、2#、3#、4# (Standard Parts)
|
|
8
|
Ultra low viscosity adapter
|
0# (Optional)
|
|
9
|
Display content
|
|
|
10
|
Viscosity
|
yes
|
yes
|
|
Temperature
|
Yes (Need to choose the temperature probe)
|
|
Rotor number
|
yes
|
|
Speed
|
yes
|
|
Auto scanning
|
yes
|
|
Thermostatic parts
|
Optional
|
|
Measurement method storage
|
No
|
|
Measurement data storage
|
No
|
30 sets
|
|
Shear rate
|
No
|
yes
|
|
Shear stress
|
No
|
yes
|
|
Motion viscosity calculation
|
No
|
Yes (Need to enter density)
|
|
11
|
Timing measurement
|
No
|
yes
|
|
12
|
Viscosity curve
|
Need an external computer
|
Real-time display of viscosity curve
|
|
13
|
Data, curve printing
|
Via computer
|
Optional thermal micro-printer direct printing
|
