- Built-in vacuum controller, High vacuum performance
- PTFE sealing
- Autolly adjust the ascending or descending of rotary flask
- Digital display and control
- Easy assembling design: to be assembled within 30 minutes.
- Double layer cooling coils for improved condenser performance.
- High quality borosilicate glass 3.3 with excellent physical and chemical properties
- Cost-saving modular design and can be customized by clients' requirements
|
Model
|
OLT-RE-10
|
|
Lifting motor power
|
40W
|
|
Heating power
|
2.2kw
|
|
Rotating flask
|
5L
|
|
Collecting flask
|
3L
|
|
Vacuum degree
|
0.098Mpa
|
|
Rotary speed
|
0-140rpm/min
|
|
Heating temp.
|
0-400C
|
|
Temp controlling accuracy
|
±1C
|
|
Glass temp range
|
-80C to 250C
|
|
Condenser tube
|
Vertical double serpentine
|
|
Bath materials
|
304 stainless steel
|
|
Host speed
|
Digital frequency stepless speed regulation
|
|
Discharge valve
|
10mm glass and lean discharge port
|
|
Bath size/volume
|
Φ300*170H(mm)
|
|
Lifting stroke
|
0-150mm
|
|
Voltage
|
220V 50Hz(various power supply and plug can be customized)
|
|
Gross weight
|
65kg
|
|
Packing size
|
790*450*1100mm(L*W*H)
|
Packing and Shipping
-The main parts will be wrapped with foam,then put into the carton; the mainbody portion will be packed in wooden cases;
-Both neutral and customized packaging can be available.
-We can ship the goods to you by International Express such as DHL,UPS,TNT,EMS and so on, you can also choose the appropriate one based on your timeline and budget. Besides,you can choose to use your own shipping agent
