Lab tabs riveting machines
SPECIFICATIONS
The device technical characteristics:
1. Suitable for supercapacitors, lithium battery tabs and lead terminal riveting;
2. The hydraulic system as a punching power, large output, speed stabilizes;
3. equipment using PL C control system to ensure stable and reliable, easy to operate;
4.The color touch screen LCD display operation, device parameterization simple and intuitive browsing;
5. The riveting punch made of high strength, high wear resistance of alloy tool steel with good abrasion resistance;
6. Grating with safety and protection door, safe and reliable equipment operation.
The equipment technical parameters:
|
Slide (indenter) Maximum stroke
|
100mm
|
|
Riveting maximum pressure
|
16t
|
|
Packing time
|
0 ~ 10 s (can be set)
|
|
Configure Power
|
AC380 / 50HZ, 6KW
|
|
Dimensions (L * W * H)
|
660 * 1100 * 1500mm
|
|
Total Weight
|
420kg
|
