Landscape Hdpe Gravel Reinforcement Grid Specification:
| Item Code |
LK-638A1 |
| Material |
HDPE |
| Size(L x W x H) |
410x430x38mm |
| Color |
Green |
| Application |
- Grass driveways and grass shoulder;
- Grass car parks;
- fairgrounds Parks;
- Disabled access;
- Overflow grass car parking lot;
- Fire truck access paths/fire lanes;
- Handicap access routes;
- Pedestrian paths;
- Golf buggy/trolley paths;
- Emergency vehicle access roads through fields;
- Modern factory building;
- Noble living communities;
- Truck maintenance and equipment yards;
|
| Compressive Strength |
120tons/m2 |
| Working Temperature |
Dimensionally stable for -40β to 90β |
| Weight |
3.4kg/sqm |
| Afforests Rate |
95%~100% |
| Porosity |
90% |
| Moisture Absorption |
0.1% |
| Environmental Compatibility |
Non toxic, harmless to plants, animals, and microorganisms, inert material, groundwater neutral |
| Anti HCL |
According to GB4218-1984, 30%x24h, no visible change |
| Anti NaOH |
According to GB4218-1984, 40%x24h, no visible change |
| Thermal Aging |
According to GB/T 7141-1999, 70ICx24h, no visible change |
| Anti UV |
According to GB/T 18830, UPE>30 T(UVA)AV<5%, qualified |
| Features and Benefits |
1. Perfect greening, provides more than 95% grass area;
2. Flat plug type overlap joint, very convenient, arbitrarily adjust expansion joint width to fit temperature change
3. Manufactured from 100% recycled plastics, eco-friendly grass grids;
4. High compressive strength and durable,the plastic grass grids is permanent and long lasting;
5. Fast and easy to install, maintenance with low cost;
6.Unique interlocking plastic grass paving grids are chemically inert, non-toxic and rot free;
|
| Packing |
Bundle or Carton (or at your request), 8pcs=2sqm=1bundle |
| MOQ |
100sqm |
| Loading Capacity |
700sqm=1x20ft container; 1420sqm=1x40ft container; 1628sqm=1x40HC container |
| Shipping |
About 20 days after receipt the deposit.
FOB Xiamen, appointed shipping-terms and port accept.
|
| Installation Guide |
|
Manufactured from 100% recycled HDPE material, Leiyuan Gravel Reinforcement Grid are an interlocking celluar paving grid system for grass and ground reinforcement applications. Because of its chemically inert and non toxic feature, grass grid allow the drainage of stormwater back into the underground soil. Except for greening, the grass grid is also designed as a sustainable solution for areas of both heavy and light traffic. During installed, the grass grids can be filled with grass or gravel surface and allow full rainwater penetration.
Gravel Reinforcement Grid harmoniously blend your architecture into the landscape in an attractive, functional and environmentally responsible way.
Gravel Reinforcement Grid Production Line:
Leiyuan Gravel Reinforcement Grid: High Strength, Long Life Service !
