Large Clear Span Wedding Tents With All Decorations
● Clear span available from 3m to 60m.
● Length: adjustable by 3m unit (SS & WS series) or 5m unit (for other series).
Features:
● No exterior guy ropes or staking required.
● No poles inside, 100% interior space be used.
● Roof and gable vent is available.
● Relocatable, easy to install, dismantle and transport.
● Full line accessories available.
Frame:
● No maintenance required.
● Extruded 4 channel aluminum hollow profiles with anodized finishing above 12um.
● All steel connectors including small parts have galvanized finishing above 60um.
● Modular character for diverse combination and expansion.
Cover:
● Kedered roof fabric and sidewalls provide weather-proof tight coverings.
● Bar tensioning roof & sidewalls system.
● Different brand fabric for option: China Fabric, Ferrari, Sioen, Verseidag.
Application:
Widely used for temporary outdoor exhibitions, wedding parties, festival celebrations, conferences, sports and other events, and also good solution of temporary warehouse, workshop and temporary emergency relief and other purposes.
The specification of Large Clear Span Wedding Tents:
|
Type
|
Span (m)
|
Side height (m)
|
Ridge height (m)
|
Bay Distance (m)
|
Roof Pitch
|
Longest Component (m)
|
Wind Load (km/h)
|
|
HS30/4-5
|
30
|
4
|
8.9
|
5
|
18°
|
10.7
|
100
|
|
HS40/4-5
|
40
|
4
|
10.5
|
5
|
18°
|
11.5
|
100
|
|
HS50/4-5
|
50
|
4
|
12.1
|
5
|
18°
|
11.5
|
100
|
|
HS60/4-5
|
55
|
4
|
13
|
5
|
18°
|
11.5
|
100
|
|
Main frame Profile
|
350x120x5mm（4-channel)
|
|
Eave Connection
|
Hot-dip Galvanized Twin Steel Plate
|
|
Roof Fixing
|
Bar Tension
|
|
Frame Material
|
Hard Pressed Extruded Aluminum 6061/T6
|
|
Cover Material
|
Double PVC coated Polyester textile, flame retardant to DIN4102 B1,M2,650-900g/sq.m
|
The accessories of Large Clear Span Wedding Tents:
