Large Outdoor Luxury Marquee Tent
Application:
Widely used for temporary outdoor weddings & parties and banquets, festival celebrations, conferences, sports event, trade show, trade fair, advertising and temporary workshops. Specially for outdoor warehouse in the cold areas because of its good performance on the snow load and for the outdoor exhibitions, sports courts because of its higher indoor space.
Available size:
Clear span available between 10-40m.
odular structure, the length is adjustable by 5m unit.
Features:
25°Roof pitch and perfect roof tension system allow Curve Tents to have better performance and survive in heavy snow situation.
Special “heart” shape appearance makes the tent more eye-attractive.
Larger indoor space as to higher ridge height than most other tent styles with same clear span.
Wind load : above 100km/h.
No exterior guy ropes or staking required.
Full line accessories available: Transparent PVC roof covers and walls, clear windows sidewalls, lining decoration, glass door, sliding door, flooring system, weight plates, anchors. glass walls, ABS hardwalls, sandwich walls are only available on the gable sides.
Frame:
No maintenance required.
Extruded 4 channel aluminum hollow profiles with anodized finishing above 12um.
All steel connectors including small parts have galvanized finishing above 60um.
Cover:
Kedered roof fabric and sidewalls provide weather-proof tight coverings.
Bar tensioning roof & sidewalls system.
Different brand fabric for option: China Fabric, Ferrari, Sioen, Verseidag.
The specification of Large Outdoor Tent :
|
Type
|
Span (m)
|
Side height (m)
|
Ridge height (m)
|
Bay Distance (m)
|
Roof Pitch
|
Longest Component (m)
|
Wind Load (km/h)
|
|
XLS20/4-5CT
|
20
|
3.9
|
8.8
|
5
|
25°
|
8
|
100
|
|
XLS25/4-5CT
|
25
|
3.9
|
9.9
|
5
|
25°
|
9.1
|
100
|
|
XLS30/4-5CT
|
30
|
3.9
|
11.2
|
5
|
25°
|
11.8
|
100
|
|
XLS40/4-5CT
|
40
|
3.9
|
13.5
|
5
|
25°
|
11.8
|
100
|
|
Main frame Profile
|
300x120x5mm （4-Channel)
|
|
Eave Connection
|
Hot-dip Galvanized Twin Steel Plate
|
|
Roof Fixing
|
Bar Tension
|
|
Frame Material
|
Hard Pressed Extruded Aluminum 6061/T6
|
|
Cover Material
|
Double PVC coated Polyester textile, flame retardant to DIN4102 B1,M2,750-900g/sq.m
|
The accessories of Luxury Tents:
