OLT-UI-4 contactless ultrasonic pulverizer, also known as cup-type crushing, is used for sterile crushing. Separated by centrifugal tubes, it can break chromosomes and break cells. It is specially designed for pre-processing of second-generation sequencing DNA samples and chromatin immunoprecipitation experimental samples. Compared with the traditional probe contact type ultrasonic cell crusher, non-contact sample can be broken under the sealed container without infectious flying fog. The ultrasonic probe will not contact with the sample to avoid cross contamination. The non - contact ultrasonic pulverizer can obtain the incomparable quality, efficiency and safety.
Multiple samples can be tested at one time with high efficiency. Without wear and slag, each sample was in a single fully enclosed test tube to avoid cross contamination. Optional cooling water circulation system, is advantageous for the sample in 4 ℃ water bath, ultrasonic energy distribution uniformity, ultrasonic role fully; The ultrasonic parameters are set flexibly, the experimental steps are standardized, the experimental repeatability is good, and the results are reliable.
Gradually, it has become an indispensable standardized tool for ChIP(chromatin immunoprecipitation) and DNA shear research platform.High efficiency, reliable results, good repeatability, minimum 5ul samples can be processed, suitable for precious samples.
[1] large LCD display, optional 7-inch touch screen control.
[2] it can detect 4 to 32 samples at the same time in a single time, with high experimental efficiency.
[3] close the system to avoid cross contamination and high security.
[4] multi-sample treatment has a wide range of applications.
[5] it can effectively prevent the production of sample foam.
[6] optional interface of cooling water circulation device can be provided with low-temperature cooling liquid circulation machine.
[7] RS485 or RS232 communication interface is optional
Model: OLT-UI-4
Power: 12-1200w continuously adjustable
Standard single processing sample size: 1.5 or 2ML*4 holes
Display mode: 4.3 "capacitive touch screen display in real color
Single ultrasound time: 0.1-99.9S
Single gap time: 0.1-99.9s
Total time (ultrasound + clearance) : 1-99h59m59s
Frequency range: 19.5-20.5KHz
Temperature control range: 0-100 degrees (low temperature is optional)
Alarm function: temperature, time, overload, no load, over temperature
Random: the amplitude Φ 20 (mm) * 1
Processing room ice bath function: not supported
Data storage: 20 sets
Power supply (optional 110V) : 220V/110V/ 50Hz/60HZ
Net size (depth * width * height) : 410*225*290 (mm)
Net weight of ultrasonic machine: 10kg
Ultrasonic main machine gross weight: 12kg
Host package (length * width * height) : 470*305*430 (mm)
Gross weight of sample treatment room: 12kg
Processing outdoor packaging (length * width * height) : 320*320*700 (mm)
Optional features: computer communication + data printing
Control mode: MCU +TFT touch control
Voice alarm and prompt: yes
Continuous ultrasound function: not supported
Optional adapter specification: 0.2ml*8 or 0.5ml*6 or 5ml*3 holes
Packing and Shipping
-The main parts will be wrapped with foam,then put into the carton; the mainbody portion will be packed in wooden cases;
-Both neutral and customized packaging can be available.
-We can ship the goods to you by International Express such as DHL,UPS,TNT,EMS and so on, you can also choose the appropriate one based on your timeline and budget. Besides,you can choose to use your own shipping agent
