Lead Acid AGM VRLA Battery

CHARACTERISTICS

CSBattery GB SERIES SEALED FREE MAINTENANCE VRLA AGM BATTERY

• Voltage: 12V 6V
• Capacity: 12V15Ah~12V250Ah 6V4Ah~6V250Ah
• Designed floating service life: 8-10 years @ 25 °C/77 °F.

> Summary for solar agm battery

CSBattery GB series lead acid batteries are designed to have a large amount of stored current discharged between charging sessions, with very heavy non-porous battery plates to withstand repeated major discharging and charging cycle. The CSBattery VRLA AGM battery uses a different chemistry for the plates active paste material, and a slightly stronger electrolyte than normal battery electrolyte, thus the GB range features 30% higher cyclic life with 10 years of float life when compared to the other standard Duration range.

> Features and Advantages for sealed free maintenance lead acid battery

• 30% more cyclic life through innovation at the PAM additives
• Long life expectancy of 10 years in floating condition
• Thick flat plate with high Tin low Calcium alloy
• Wide operating temperature range from -20 °C to 50°C
• 3% Low self-discharge rate
• Very good deep cycle performance: up to 700 cycles @50% DOD
• Excellent deep discharge recovery capability

> Construction for VRLA AGM battery

• Positive plate – Thick high Sn low Ca grid with special paste
• Negative plate – Balanced Pb-Ca grid for improved recombination efficiency
• Separator – Advanced AGM separator for high pressure cell design
• Electrolyte – Dilute high purity sulfuric acid
• Battery container and cover –Fire resistance ABS, water proof
• Pillar seal – Two layers epoxy resin seal
• Relief valve – Complete with integrated flame arrestor

> Charging voltage and settings for Sealed MF VRLA AGM battery

• Constant voltage charging is recommended
• Recommended float charge voltage: 2.27V/cell @20~25°C
• Float voltage temperature compensation: -3mV/°C/cel l
• Float voltage range: 2.27 to 2.30 V/cell @ 20~25°C
• Cyclic application charge voltage : 2.40 to 2.47 V/cell @ 20~25°C
• Max. charge current allowable : 0.25C

> Complied standards

• Ø IEC 60896-21/22   Ø IEC 61427  Ø ISO9001/14001/18001   Ø Eurobat guide, long life
• Ø BS6290 part 4  Ø GB/T 22473  Ø CE   Ø IATA and IMDG

> Applications for VRLA SMF battery

• Ø Electric Powered Vehicles, Ø Golf Cars and Buggies, Ø Wheel Chairs, Ø Power Tools, Ø Electric Powered Toys,
• Ø Control System, Ø Medical Equipments, Ø UPS systems, Ø Inverter systems, Ø Servers, Ø Telecom,
• Ø Emergency systems, Ø Security systems, and so on.

> GB Delivery time

• Normal, 25-30 days for production with injection molding Lead-plate by ourself
• As a factory we Can Support Urgent project with 10-15days.
• OEM brand is free charge.
