It is all aluminum alloy waterproof structure, stylish, generous, easy to install. Two sizes design, 1 meter and 0.5 meter. 1 meter uses 18*8W RGBW LEDs as the light source, 0.5 meter uses 8*8W RGBW LEDs as the light source, and the light output angle is 25 ° (optional 10 ° 45 °). Each light can be individually controlled. A high-capacity lithium battery is used. It can work for a long time, and the display panel can display the battery capacity. The reasonable LED layout makes the projected light spot more uniform, the color mixing is more pure, and the projection distance is longer. It can be widely used for projection lighting, outdoor bright talk, etc. In addition to DMX control, there is also a powerful RDM control.
● Optics
. LED：
※ 18x8W RGBW LED(1 meter)
※ 8x8W RGBW LED(0.5 meter)
. Lens: 43mm PMMA lens with high brightness
. Beam angle: 25 ° (optional 10 °, 45 °)
. Life span : 50000H, low power consumption, energy saving and environmental protection
● Colour
. Uniform RGBW color mixing system
. White balance can be adjusted manually
. Static color setting
● Specification
. 5 DMX channel modes: 1CH / 4CH / 7CH / 32CH / 35CH international standard DMX512 channels
. 3 control modes: DMX512, wireless DMX, master-slave
. Battery capacity：
※ 13200mAH(0.5 meter)
※ 26400 mAH(1 meter)
. Battery life: 4 hours at full power, 8 hours running program
. Light spot angle: 25 ° (optional 10 °, 45 °)
. DMX function: dimming, strobe, RGBW, macro color, color jump, color gradation, rainbow, auto-run program selection, auto-run speed, dimming curve selection, function setting.
. Stand-alone mode: color jump, color gradient, auto-run, slave, macro color, static color setting, rainbow, auto-run program selection
. Strobe effect :Puls Random、Ramp up Random、Ramp down Random、Random strobe、Strobe Breakeffect, 5s…..1s、Strobe0-20Hz
. Dimming: 0-100% 16bit dimming, which can control the change of light and dark and close light
. Dimmer mode: 2 kinds.(LED and Halogen)
● Display
. 1.3-inch OLED display
. High anti-interference four-button touch button
. Key lock can be set to prevent misoperation
. The display board can be reversed by 180 °, which is suitable for installation in unreasonable positions.
● Software
. Software update :Update via DMX link
. Display the lamp usage time, which is convenient for customers to understand the lamp usage in time
. LED refresh frequency: 3000hz
. 4 kinds of dimming curve:Linear Dimmer、Sqaure Dimmer、.Sqaure Dimmer、S-Curve Dimmer
● Other functions
. Setting and addressing: RDM
. LED temperature detection system to protect the life of light
● Power / DMX connection
. Power connection: Waterproof power socket Seetronic powerCON IN (SAC3MPX) / OUT (SAC3FPX)
. DMX input: Waterproof DMX card dragon seat 3-pin Seetronic J3F2C-W
. DMX output: Waterproof DMX card dragon seat 3-pin Seetronic K3F2C-W
● Power
. AC100-240V 50/60HZ
. Power consumption：
※ 65W（0.5 meter）
※ 140W（1 meter）
● Protection class
. Housing material: die-cast aluminum
. Waterproof level: IP65
● Working environment
. Indoor working temperature: -20 ° C ～ + 40 ° C
● Size and weight
. Packing size: 535x225x230mm(0.5 meter), 1075x225x230mm(0.5 meter),
. Net weight: 5.3KG(0.5 meter),10KG(1 meter)
. Gross weight: 6.4KG(0.5 meter),11.6KG(1 meter)
● Certification
. CE,ROHS
