LF26650 3.2V 3400mAh LiFePO4 cell used for solar street light, solar storage system etc
S/N
|
Details
|
Parameters
|
Remarks
|
|
1 |
Nominal voltage |
3.2V |
Mean Operation Voltage |
|
2 |
Rated capacity |
Typical |
3400mAh |
Standard discharge(0.2C) after standard charge |
Minimum |
3400mAh |
|||
3 |
Charge |
Charge voltage |
3.65±0.2V |
|
Charge Mode |
0.2C to 3.65V, then 3.65V to 0.02C (CC/CV) |
|||
Standard Charge current |
680mA |
|||
Max charge current |
1700mA |
|||
Charge cut-off voltage |
3.65±0.2V |
|||
Recommended float charge voltage ( for standby use) |
3.45±0.1V |
|||
4 |
Discharge |
Standard discharge current |
680mA |
|
Max continuous discharge current |
3400mA |
|||
Max. Pulse current |
10200mA (<30min) |
|||
Discharge Cut-off voltage |
2V |
|||
5 |
Cycle life |
≥ 2000 cycles |
0.2C 100% DOD |
|
6 |
Operation Temperature Range |
Charge:0~45℃ |
60±25%R.H. Bare Cell |
|
Discharge:-20~60℃ |
||||
7 |
Storage Temperature Range |
0~35℃ |
60±25%R.H. at the shipment state |
|
8 |
Weight |
Approx: 85g |
|
|
9 |
Size |
Φ26.3 X 66.5mm |
|
