LF32650 3.2V 6000mAh LiFePO4 battery used for solar storage system, solar light etc

S/N

Details

Parameters

Remarks

1

Nominal voltage

3.2V

Mean Operation Voltage

2

Rated capacity

Typical

6Ah

Standard discharge（0.2C）

after standard charge

Minimum

6Ah

3

Charge

Charge voltage

3.65±0.2V

Charge Moe

0.2C to 3.65V, then 3.65V to 0.02C (CC/CV)

Standard Charge current

6A

Max charge current

6A

Charge cut-off voltage

3.65±0.2V

Recommended float charge voltage ( for standby use)

13.8±0.1V

4

Discharge

Standard discharge current

3A

Max continuous discharge current

6A

Max. Pulse current

30A (＜3s)

Discharge Cut-off voltage

2.0V

5

Cycle life

≥ 2000 cycles

 0.5C 100% DOD

6

Operation Temperature

Range

Charge：0~45℃

60±25%R.H. Bare Cell

Discharge：-20~60℃

7

Storage Temperature

Range

0~40℃

60±25%R.H. at the shipment state

8

Weight

Approx：145kg

9

Size

32.5 x 70.9mm

10

Plastic Case

ABS
