Lithium Ion Polymer Battery 48V 100AH Lithium Battery

A lithium-ion battery or Li-ion battery is a type of rechargeable battery.

Facebook Twitter Pinterest LinkedIn 分享

PRODUCT DETAILS

  Lithium Ion Polymer Battery 48V 100AHLithium Ion Polymer Battery 48V 100AHLithium Ion Polymer Battery 48V 100AH

Basic Parameters
US2000
Phantom-S
SW-48100
Nominal Voltage (V)
48
48
51.2
Nominal Capacity (Wh)
2400
2400
5120
Usable Capacity (Wh)
2200
2200
4196
Dimension (mm)
442*410*89
440*440*88.5
482*400*177
Weight (Kg)
24
24
45
Discharge Voltage (V)
45 ~ 53.5
45 ~ 53.5
37.5-54.7
Charge Voltage (V)
52.5 ~ 53.5
52.5-53.5
48-54.7
Charge / Discharge Current (A)
25(Recommend)
25(Recommend)
50 (Recommend)
50 (Max)
50 (Max)
100(Max)
100 (Peak© 15s)
100 (Peak© 15s)
100 (Peak@15s)
Communication Port
RS485, CAN
RS485. CAN
RS485. CAN
Single string quantity(pcs)
8
8
8
Working Temperature/"C
-20~60
-80
-80
Shelf Temperature/°C
-80
-20 〜60
-80
Humidity
5%~85%
5%~85%
5%~85%
Altitude (m)
<4000
<4000
<4000
Design life
15+Years (25°C/77°F)
15+Years (25°C/77T)
15+Years (25aC/77T)
Cycle Life
>6000, 25C
>6000, 25 C
>6000, 25C
Authentication Level
IEC62619/CE/UN38.3
IEC62619/CE /UN38.3
IEC62619/CE /UN38.3
Lithium Ion Polymer Battery 48V 100AH

Lithium Ion Polymer Battery 48V 100AH
