Parameter
| Manufacturer |
Texas Instruments |
| Product Category |
Switching Voltage Regulators |
| Mounting Style |
SMD/SMT |
| Package / Case |
WSON-10 |
| Number of Outputs |
1 Output |
Series
|
LM5010
|
Input Voltage - Min
|
8 V
|
Input Voltage - Max
|
75V |
Minimum Operating Temperature
|
- 40 C
|
Maximum Operating Temperature
|
+ 125 C
|
Packaging
|
Reel/Cut Tape
|
Factory Pack Quantity
|
1000 |
Introduction
LM5010SD is a high voltage, 1-Ampere synchronous buck regulator. It has a wide input voltage range of 4.5 V to 75 V and is designed to provide a regulated output voltage from 0.8 V to 60 V. The LM5010SD operates at a fixed frequency of 100 kHz, 200 kHz, or 400 kHz and utilizes a constant on-time, valley current-mode control scheme to provide fast transient response and excellent loop stability. The device features a high-side MOSFET and a low-side MOSFET with internal gate drivers, which allows for a simple and compact design. It also includes various protection features such as under-voltage lockout (UVLO), thermal shutdown, and over-current protection. The LM5010SD is available in a 10-lead, thermally enhanced WSON package, making it suitable for various applications such as telecom, industrial, and automotive power supplies.
Application
The LM5010SD is a versatile synchronous buck regulator designed for use in a range of applications including telecom, industrial, and automotive power supplies. With a wide input voltage range of 4.5 V to 75 V and a regulated output voltage range of 0.8 V to 60 V, this device provides excellent regulation and fast transient response. The LM5010SD operates at a fixed frequency of 100 kHz, 200 kHz, or 400 kHz, and features a constant on-time, valley current-mode control scheme. The device includes a high-side MOSFET and a low-side MOSFET with internal gate drivers, simplifying the design and reducing component count. Additionally, the LM5010SD includes protection features such as under-voltage lockout, thermal shutdown, and over-current protection, making it ideal for a wide range of industrial applications.
