3 Axle 40ft Powerstar Container Flatbed semi trailer
Applications:
3 Axle 40ft Flatbed Semi trailer (also called Tri axle container flatbed trailer, 3 Axle flatbed semi trailer with spring suspension,Cargo flatbed semi trailer, Platform truck semi trailer, Customer made container semi trailer) are widely used to carry 20 foot and 40 foot ISO shipping containers.
As one of the featured products of Powerstar truck, our flatbed trailers have earned reputation for reliable quality from world-wide customers.
Key Features:
---- 15 years Manufacturer experience.
---- Payload: 20ton, 30ton, 40ton, 60ton to 100ton.
---- Export to More than 70 Countries or Area.
---- Certificate: ISO9001, COC, PVOC, CIQ, SONCAP, BV, FORM E.
---- Quickly delivery to Worldwide.
Specifications:
3-AXLE 35,000LITERS SULFURIC ACID TANKER
Main Dimensions:
Overall Length: 11800mm
Overall Height: 3500mm
Overall Width: 2500mm
Tare Weight: 10500kg
Loading Capacity: 50000kg
Tank Body:
Shape Mono block Cylinder
Total Volume (m3): 35CMB
Tanker Body Material: 6 mm carbon steel
End plate: 6 mm carbon steel
Inner Lining: 16 mm plastics
Manhole cover: ∮500mm ,2 sets with 2 breather valve, plastics made
Discharging valve: 2 sets ∮100mm discharging valve, stainless made
Safety valve : 1 set of safety valve
Discharging Pipe: 4” rubber hose, 2pcs, 6m long
Chassis :
Axle : 3 axles
BPW 13 ton
Landing Gear: JOST brand Two-speed, manual operating, heavy duty landing gear
King Pin: JOST brand 2” bolt-in king pin
Suspension: Air suspension
Braking System: WABCO RE 6 relay valve; T30/30 Spring brake chamber; 40L air tanks.
Wheel rim: 9.0-22.5 wheel rim, 12 pieces
Tire: 12R22.5 tubeless tire , 12 pieces
Painting: Complete Chassis sand blasting to clean rust, 1 coat of anti-corrosive prime, 2 coats of final paint
Accessories: One standard tool box, one spare tyre and carrier
---- SGS, BV, CONTECNA, CE Qualified.
---- Local engineer training support.
---- 12 months FREE parts.
---- Factory genuine parts supply.
---- 7 days to worldwide by DHL.
