LPM-261 2inch thermal label panel mount printers support cash box
LPM-261 is a direct thermal panel mount printer, printing thermal label and receipt. It not only combines the advantages of embedded thermal printer before, but also add new features. One is super diameter, it can accommodate 60mm diameter scroll, solve the problem of putting paper frequently. The other is cash box support.
Feature:
1. Smart appearance, easy paper loading
2. Low noise thermal printing
3. Different interfaces for choose
4. Front panel make paper replacement
5. Support image-text printing
6. Support Max 60mm diameter thermal paper or thermal label paper
7. Support label space detection (black mark detection as optional)
8. Support cash box (optional)
Specification:
| Model No.
|
LPM-261
|
| Print
|
Print Method: Thermal line printing
Printing Speed: Max. 90mm/s
Resolution: 8dots/mm, 384dots/line
Effective Printing Width: 48mm
|
| Character
|
Character Set: ASCII, GB2312, BIG5...
Print Font: ANK:(9*17, 12*24), Chinese:(24*24)
|
| Paper Spec.
|
Paper Type: Thermal paper/Thermal label roll
Paper Width: 57.5±0.5mm
Paper Roll Diameter: Max. 60mm
|
| Head Temp. Detection
|
Via thermistor
|
| Out of paper detection
|
Via photo interrupter
|
| Label detection
|
Label gap detection
|
| Baud rate
|
9600bps-115200bps
|
| Interface
|
RS232/TTL, USB, DRAWER
|
| Physical
|
Outline Dimension: 95W*101L*69.3H mm
Installation Port Size: 90*96.5mm
Color: Black/white
|
| Power
|
DC5-9V/12V
|
| Environment
|
Working Temperature:0℃-50℃
|
Application:
1. Label scale
2. Logistic
3. Taxi meter print proposal
4. Recording meter print proposal
5. Self-service print proposal
6. Ticket machine print proposal
7. Medical instrument print proposal
8. Weight machine print proposal
9. Electronic instrument print proposal
10. Test instrument print proposal
Company Information:
We are a professional manufacturer of thermal printers since 2011.Our main products are handheld thermal printer, impact dot matrix printer, panel thermal printer, kiosk ticket printer, pos printer and label barcode thermal printer, etc. We have a wealth of in dependent research and experience, which can effectively meet different customers ODM requirements and help achieve printing simply, efficiently and economically. Currently, Our products are exported to Southeast Asia, South Asia, South & North America, Middle East and Europe, etc.
FAQ:
Q: About samples
A: Samples are available for testing.
Q: Delivery date.
A: All the printers for samples are in stock, can ship it within 2 days after payment received. For bulk order
delivery date approximately 2 weeks.
Q: Payment terms
A: Paypal, western union, T/T in advance.
Q: Warranty
A: One year warranty. During warranty period, the damage caused by non-human factor, CASHINO will be
responsible for the free repair. Overdue warranty period, CASHINO will continue to provide services with
reasonable price to the customer.
